EXPERIMENTAL STUDY OF MULTI-SCALE REACTION BETWEEN ACID AND ROCK IN ACID FRACTURING
-
摘要: 前人有关碳酸盐岩与酸液反应的研究多局限于单一尺度,尚缺乏对酸岩反应特征的多尺度探索。该文采用正交实验方法,进行了9次四川二叠系长兴组灰岩颗粒的酸液溶蚀实验,探索了主体酸浓度、温度、反应时间和酸型等4种因素影响下的宏观反应速率和介观反应机理。在所分析的因素中,酸型对宏观反应速率影响最强,其次是主体酸浓度。酸蚀前后的岩样在扫描电镜下的孔、缝、面的变化表现出多样性,表明碳酸盐岩酸蚀存在多种介观机理,前人所述的酸液对碳酸盐岩"通缝扩喉"的反应机理,只是其中的一种情况。对比不同尺度的反应特征,发现宏观反应速率与介观反应机理之间的相关性不明显。Abstract: Most of previous researches about acid/rock reaction are single scale and lack of multi-scale investigations.With orthogonal experiment method,nine acid erosion experiments of limestone particles,obtained from Changxing Formation of Permian in Sichuan Province,were designed and carried out.From the experiments result,it is discussed that the macroscopical reaction rate and mesoscopic reaction mechanism,which are influenced by four factors such as main acid concentration,temperature,reaction duration and acid type.The macroscopical reaction rate is most greatly affected by acid type,which is followed by main acid concentration.The rock mesoscopic structures observed by scanning electron microscope,such as pores,fractures and surfaces patterns,may be variously changed by acid erosion.In other words,there are various mesoscopic erosion mechanisms of carbonate rock."communicating fractures and expanding pore throat",summarized by previous researchers,is only a special case of mesoscopic erosion mechanism of limestone.When it comes to the relationship of different scale reaction properties,there is no obvious correlation between macroscopical reaction rate and mesoscopic reaction mechanism.
-
Key words:
- multi-scale /
- reaction /
- experiment /
- carbonate /
- acid fracturing
-
[1] 佚名.名词术语释义--宏观领域、介观领域与微观领域[J].微纳电子技术,2003,(1):11. [2] VAN KAMPEN N G.The Expansion of the Master Equation[J].Advances in Chemical Physics,1976,34:245-309. [3] 张建利,孙忠杰,张泽兰.碳酸盐岩油藏酸岩反应动力学实验研究[J].油田化学,2003,20(3):216-219. [4] 郭文英,赵立强,曾晓慧.多氢酸酸液体系的性能评价[J].石油与天然气化工,2007,36(2):139-141. [5] 陈赓良,黄瑛.碳酸盐岩酸化反应机理分析[J].天然气工业,2006,26(1):104-108. [6] NIERODE D E,WILLIAMS B B.Characteristics of Acid Reaction in Limestone Formations[J].SPE Journal,1971,11(4):406-418. [7] 龚明.计算酸压裂缝导流能力的新模型[J].天然气工业,1999,19(3):68-72. [8] KALIA N,BALAKOTAIAH V.Modeling and analysis of wormhole formation in reactive dissolution of carbonate rocks[J].Chemical Engineering Science,2007,62(4):919 -928. [9] RUFFET C,FERY J J,ONAISI A.Acid fracturing treatment:a surface topography analysis of acid etched fractures to determine residual conductivity[J].SPE Journal,1998,3(2):155-162. [10] MALAGON C,POURNIK M,HILL A D.The texture of acidized fracture surfaces--implications for acid fracture conductivity[J].SPE Production & Operations,2008,23(3):343-352. [11] 罗渝然,高盘良.化学动力学进入微观层次[J].化学通报,1986,(8):56-59. [12] POMES V,BAZIN B,GOLFIER F,et al.On The Use of Upscaling Methods to Describe Acid Injection in Carbonates[C]// SPE Annual Technical Conference and Exhibition,New Orleans,Louisiana,September 30-October 3,2001.New Orleans:Society of Petroleum Engineers Inc,2001. [13] 魏宝和.盐酸酸化碳酸盐岩样品的扫描电镜观测[J].油田化学,1993,10(1):23-27. [14] 贺伟,冯文光,贺承祖.碳酸盐岩储层酸蚀反应机理的实验研究[J].天然气勘探与开发,2000,23(2):27-30. [15] 张守鹏,王伟庆,夏云.提高油层渗透率的酸-岩作用原理与油层改造应用实例[J].石油实验地质,2000,22(1):77-80. -
