基于恒速压汞技术的特低—超低渗砂岩储层微观孔喉特征

高辉; 解伟; 杨建鹏; 张创; 孙卫

doi:10.11781/sysydz201102206

基于恒速压汞技术的特低—超低渗砂岩储层微观孔喉特征

doi: 10.11781/sysydz201102206

高辉¹,
解伟²,
杨建鹏³,
张创²,
孙卫⁴

1.
西安石油大学, 石油工程学院, 西安, 710065
2. 陕西延长石油(集团)有限责任公司研究院, 西安, 710075
3. 陕西延长石油(集团)有限责任公司延长油田股份有限公司南区采油厂, 陕西, 延安, 716000
4. 西北大学, 地质学系, 西安, 710069

基金项目: “十一.五”国家科技支撑计划项目(2007BAB17B02);陕西省教育厅2010年科学研究计划项目(2010JK778)资助

详细信息

作者简介:
高辉(1979- ),男,博士,讲师,从事油气田地质与开发方面的教学和科研工作.E-mail:ghtopsun@yahoo.com.cn.

中图分类号: TE348
计量
- 文章访问数: 3142
- HTML全文浏览量: 96
- PDF下载量: 1270
- 被引次数: 0
出版历程
- 收稿日期: 2010-08-13
- 修回日期: 2011-02-09
- 刊出日期: 2011-04-28

Pore throat characteristics of extra-ultra low permeability sandstone reservoir based on constant-rate mercury penetration technique

1.
College of Petroleum Engineering, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China
2. Research Institute of Shaanxi Yanchang Petroleum(Group), Co, Ltd, Xi'an, Shaanxi 710075, China
3. Southern Oil Production Plant, Yanchang Oilfield Corporation, Shaanxi Yanchang Petroleum (Group), Co, Ltd, Yan'an, Shaanxi 716000, China
4. Department of Geology, Northwest University, Xi'an, Shaanxi 710069, China

摘要

摘要: 基于恒速压汞测试结果,对鄂尔多斯盆地延长组特低、超低渗砂岩储层的微观孔喉特征进行了分析,定量表征了孔喉特征参数的变化。结果表明,特低、超低渗储层的孔隙半径分布特征相似,介于100~200μm之间,峰值基本在140μm左右;相对于特低渗储层而言,超低渗储层的喉道分布范围更窄,小于1μm的喉道含量较高,变化更为敏感,孔喉半径比分布范围较宽,喉道进汞饱和度受渗透率影响较大;特低、超低渗储层孔喉特征的差异主要体现在喉道上。总体毛细管压力曲线表现出3个变化阶段,渗透率不同,各阶段受孔隙和喉道的影响程度也不同;处于中后期的超低渗储层更应注重喉道的开发。
- 孔喉特征 /
- 储层品质 /
- 恒速压汞 /
- 特低—超低渗砂岩储层 /
- 鄂尔多斯盆地
Abstract: Based on constant-rate mercury penetration technique, micro pore throat characteristics of extraultra low permeability sandstone reservoir of the Yangchang Formation in the Ordos Basin were analyzed, and the alterations of pore throat characteristic parameters were also quantitatively characterized. Pore radiuses were similar, usually 100～200 μm, and the peak values were about 140 μm. Compared to those in the extra-low permeability reservoir, distribution ranges of throat in the ultra-low permeability reservoir were narrow. Throats less than 1 μm accounted for large amount, and were more sensitive to permeability. Distribution ranges of pore throat radius ratio were wide and permeability had big influence on input mercury saturation of throat in ultra-low permeability reservoir. The differences of pore throat characteristics between extra-and ultra-low permeability sandstone reservoir mainly lay in throats. 3 variation periods were identified on overall capillary pressure curves. Each period was affected by pore or throat in different extent due to different permeability. Throats should be focused on in the ultra-low permeability reservoir during the middle and latter stages.
- pore throat characteristics /
- reservoir quality /
- constant-rate mercury penetration /
- extra-ultra low permeability sandstone reservoir /
- Ordos Basin

HTML全文

参考文献(14)

[1]	杨正明,张英芝,郝明强,等.低渗透油田储层综合评价方法[J].石油学报,2006,27(2):64-67.
[2]	郝明强,刘先贵,胡永乐,等.微裂缝性特低渗透油藏储层特征研究[J].石油学报,2007,28(5):93-98.
[3]	于俊波,郭殿军,王新强.基于恒速压汞技术的低渗透储层物性特征[J].大庆石油学院学报,2006,30(2):22-25.
[4]	王瑞飞,沈平平,宋子齐,等.特低渗透砂岩油藏储层微观孔喉特征[J].石油学报,2009,30(4):560-563.
[5]	王金勋,杨普华,刘庆杰,等.应用恒速压汞实验数据计算相对渗透率曲线[J].石油大学学报(自然科学版),2003,27(4):66-69.
[6]	林玉保,张江,刘先贵,等.喇嘛甸油田高含水后期储集层孔隙结构特征[J].石油勘探与开发,2008,35(2):215-219.
[7]	胡志明,把智渡,熊伟,等.低渗透油藏微观孔隙结构分析[J].大庆石油学院学报,2006,30(3):51-53.
[8]	孙卫,杨希濮,高辉.溶孔一粒间孔组合对超低渗透储层物性的影响:以西峰油田庆阳区长8油层为例[J].西北大学学报(自然科学版).2009,39(3):507-509.
[9]	刘小洪,罗静兰,郭彦如.等.鄂尔多斯盆地陕北地区上三叠统延长组长6油层组的成岩相与储层分布[J].地质通报,2008,27(5):626-632.
[10]	窦伟坦,景春,王峰,等.鄂尔多斯盆地长6油层组储集砂岩成岩作用及其对储层性质的影响[J].成都理工大学学报(自然科学版),2009,36(2):153-158.
[11]	于波,崔智林,刘学刚,等.西峰油田长8储层砂岩成岩作用及对孔隙影响[J].吉林大学学报(地球科学版),2008,38(3):405-409.
[12]	朱玉双,柳益群,赵继勇,等.不同流动单元微观渗流特征研究:以华池油田长3油藏华152块为例[J].石油实验地质,2008,30(1):103-108.
[13]	孙卫,曲志浩,李劲峰.安塞特低渗透油田见水后的水驱油机理及开发效果分析[J].石油实验地质,1999,21(3):256-259.
[14]	熊伟,雷群,刘先贵,等.低渗透油藏拟启动压力梯度[J].石油勘探与开发,2009,36(2):232-235.
