川西孝泉—新场地区须家河组四段裂缝分布特征

张克银

doi:10.11781/sysydz201404398

川西孝泉—新场地区须家河组四段裂缝分布特征

doi: 10.11781/sysydz201404398

张克银

中国石化西南油气分公司勘探开发研究院, 成都 610041

基金项目: 国家科技重大专项课题“四川盆地碎屑岩层系大中型油气田形成规律与勘探方向”（2011ZX05002-004）资助。

详细信息

作者简介:
张克银（1967—），男，高级工程师，从事油气地质综合研究。E-mail: zhang_ky99@126.com。

中图分类号: TE122.2⁺3
计量
- 文章访问数: 746
- HTML全文浏览量: 61
- PDF下载量: 539
- 被引次数: 0
出版历程
- 收稿日期: 2014-01-10
- 修回日期: 2014-06-10
- 刊出日期: 2014-07-28

Fracture distribution characteristics of 4th member of Xujiahe Formation in Xiaoquan-Xinchang area, western Sichuan

Zhang Keyin

Exploration & Production Research Institute, SWPB of SINOPEC, Chengdu, Sichuan 610041, China

摘要

摘要: 通过电成像测井的手段，对研究区内19口重点井须家河组四段发育的天然裂缝资料进行了统计、分析，认为该层位裂缝主要有4组:印支晚期—燕山早期的NE-SW向裂缝，燕山中、晚期的近SN向裂缝，喜马拉雅晚期的NW-SE向裂缝和喜马拉雅期四幕的ESE-WNW至ENE-WSW向裂缝；孝泉—新场地区须家河组四段主要发育低角度斜交裂缝以及高角度斜交裂缝，水平缝发育较少，垂直缝基本不发育；背斜南、北两翼的裂缝线密度要大于轴部，背斜轴部总体上表现为距断裂系统越近、裂缝的线密度越大的特点；裂缝线密度的不均质性较强；中砂岩、细砂岩、砾岩、粗砂岩是裂缝的主要载体，裂缝在中砂岩、细砂岩、砾岩、粗砂岩中发育得更好，而页岩中的裂缝最不发育；页岩、泥质粉砂岩、粉砂岩中的裂缝线密度呈较清晰的随层厚增加而减小的趋势；粉砂质页岩、粗砂岩中裂缝线密度与层厚没有表现出明显的对应关系。
- 裂缝 /
- 成像测井 /
- 须家河组四段 /
- 孝泉—新场地区 /
- 川西
Abstract: Electro-imaging logging was carried out in 19 key wells to study the natural fractures in the 4th member of the Xujiahe Formation in the western Sichuan Basin. There are 4 sets of fractures as followed: the NE-SW trended fractures from the late Indosinian to the early Yanshanian, the SN trended fractures during the middle and late Yanshanian, the NW-SE trended fractures during the late Himalayan, and the ESE-WNW to ENE-WSW trended fractures during the 4th phase of Himalayan. Low-angle and high-angle diagonal fractures account for a large proportion, while horizontal fractures less and vertical fractures seldom develop. The fractures in the southern and northern flanks have bigger linear densities than those in the hinge, where the linear densities of fractures increase as closing to fault system, showing obvious heterogeneity. Medium sandstones, fine sandstones, conglomerates and coarse sandstones are favorable carriers for fractures. In contrast, fractures are underdeveloped in shales. In shales, pelitic siltstones and siltstones, the linear density of fractures decreases obviously as formation thickness increases. As to silty shales and coarse sandstones, there is no apparent congruent relationship.
- fracture /
- imaging logging /
- 4th member of Xujiahe Formation /
- Xiaoquan-Xinchang area /
- western Sichuan

HTML全文

参考文献(25)

[1]	杨克明,朱宏权,叶军,等.川西致密砂岩气藏地质特征[M].北京:科学出版社,2012. Yang Keming,Zhu Hongquan,Ye Jun,et al.The geological characteristics of tight sandstone gas reservoirs in west Sichuan basin[M].Beijing:Science Press,2012.
[2]	郭正吾,邓康龄,韩永辉,等.四川盆地形成与演化[M].北京:地质出版社,1996. Guo Zhengwu,Deng Kangling,Han Yonghui,et al.The formation and development of Sichuan basin[M].Beijing:Geological Publishing House,1996.
[3]	于福生,王彦华,李晓剑,等.川西坳陷孝泉—丰谷构造带变形特征及成因机制模拟[J].地球科学与环境学报,2011,33(1):45-53. Yu Fusheng,Wang Yanhua,Li Xiaojian,et al.Deformation Characteristics and Genetic Simulation of Xiaoquan-Fenggu Structural Belt in West Sichuan Depression[J].Journal of Earth Sciences and Environment,2011,33(1):45-53.
[4]	曾洪扬,陈洪德,林良彪,等.川西前陆盆地晚三叠世构造层序岩相古地理特征[J].石油实验地质,2009,31(1):46-49. Zeng Hongyang,Chen Hongde,Lin Liangbiao,et al.Tectonic and sequence-based lithofacies paleogeographic features of Late Triassic in Western Sichuan foreland basin[J].Petroleum Geology & Experiment,2009,31(1):46-49.
[5]	林良彪,陈洪德,胡晓强,等.四川盆地上三叠统构造层序划分及盆地演化[J].地层学杂志,2007,31(4):415-422. Lin Liangbiao,Chen Hongde,Hu Xiaoqiang,et al.Classification of tectonic sequence and basin evolution of the upper Triassic in the Sichuan basin[J].Journal of Stratigraphy,2007,31(4):415-422.
[6]	孟万斌,吕正祥,刘家铎,等.川西坳陷孝泉—新场地区须家河组四段储层控制因素及预测地质模型[J].石油与天然气地质,2013,34(4):483-490. Meng Wanbin,Lü Zhengxiang,Liu Jiaduo,et al.Reservoir controlling factors and geological prediction models of the 4th member of the Xujiahe Formation in Xiaoquan-Xinchang area,the western Sichuan Basin[J].Oil & Gas Geology,2013,34(4):483-490.
[7]	杨克明.川西坳陷须家河组天然气成藏模式探讨[J].石油与天然气地质,2006,27(6):786-793. Yang Keming.Gas reservoiring mode in Xujiahe Formation of western Sichuan depression[J].Oil & Gas Geology,2006,27(6):786-793.
[8]	葛祥,张筠,吴见萌.川西须家河组致密碎屑岩裂缝与储层评价[J].测井技术,2007,31(3):211-215. Ge Xiang,Zhang Yun,Wu Jianmeng.Fracture and reservoir evaluation for tight clastic rock of Xujiahe formation in west Sichuan[J].Well Logging Technology,2007,31(3):211-215.
[9]	白玉彬,赵靖舟,陈孝平,等.蟠龙油田长2储层裂缝分布及油气地质意义[J].断块油气田,2012,19(1):61-64. Bai Yubin,Zhao Jingzhou,Chen Xiaoping,et al.Fracture distribution and geological significance of Chang 2 reservoir in Panlong Oilfield[J].Fault-Block Oil and Gas Field,2012,19(1):61-64.
[10]	李晓燕,蒋有录,陈涛.古风化壳孔隙与裂缝发育特征及其油气地质意义[J].地球科学与环境学报,2010,32(1):60-64. Li Xiaoyan, Jiang Youlu, Chen Tao.Characteristics and Petroleum Geological Significance of Pores and Fissures Developed in the Paleo Weathered Crust[J].Journal of Earth Sciences and Environment,2010,32(1):60-64.
[11]	Nelson R A,Amoco B,Houston T.Geologic analysis of naturally fractured reservoirs[M].Woburn:Gulf Professional Publishing,2001.
[12]	王志萍,秦启荣,王保全.川西DY地区致密砂岩储层裂缝特征及其成藏意义[J].断块油气田,2012,19(5):572-576. Wang Zhiping,Qin Qirong,Wang Baoquan.Fracture characteristics and its hydrocarbon accumulation significance of tight sandstone reservoir in DY Region of west Sichuan[J].Fault-Block Oil and Gas Field,2012,19(5): 572-576.
[13]	李阳兵,张筠,徐炳高,等.川西地区须家河组裂缝成因类型及形成期次的成像测井分析[J].测井技术,2010,32(4):348-351. Li Yangbing,Zhang Jun,Xu Binggao,et al.On the origin types and formation periods of fractures in Xujiahe formation in west Sichuan region[J].Well Logging Technology,2010,32(4):348-351.
[14]	张筠,徐炳高.成像测井在川西碎屑岩解释中的应用[J].测井技术,2005,29(2):129-132. Zhang Jun,Xu Binggao.Application of imaging logging interpretation in west Sichuan detrital rock[J].Well Logging Technology,2005,29(2):129-132.
[15]	李建良,葛祥,张筠.成像测井新技术在川西须二段储层评价中的应用[J].天然气工业,2006,26(7):49-51. Li Jianliang,Ge Xiang,Zhang Jun.Application of image logging technology to evaluation of reservoirs in the 2nd member of Xujiahe Fm in the Western Sichuan Basin [J].Natural Gas Industry,2006,26(7):49-51.
[16]	陈迎宾,郑冰,袁东山,等.大邑构造须家河组气藏裂缝发育特征及主控因素[J].石油实验地质,2013,35(1):29-35. Chen Yingbin,Zheng Bing,Yuan Dongshan,et al.Characteristics and main controlling factors of fractures in gas reservoir of Xujiahe Formation,Dayi Structure[J].Petroleum Geology & Experiment,2013,35(1):29-35.
[17]	黄继新,彭仕宓,王小军,等.成像测井资料在裂缝和地应力研究中的应用[J].石油学报,2006,27(6):65-69. Huang Jixin,Peng Shimi,Wang Xiaojun,et al.Applications of imaging logging data in the research of fracture and ground stress[J].Acta Petrolei Sinica,2006,27(6):65-69.
[18]	周文.裂缝性油气储集层评价方法[M].成都:四川科学技术出版社,1998. Zhou Wen.Fractured oil and gas reservoir evaluation methodology[M].Chengdu:Sichuan Science and Technology Press,1998.
[19]	周新桂,操成杰,袁嘉音,等.油气盆地储层构造裂缝定量预测研究方法及其应用[J].吉林大学学报:地球科学版,2004,34(1):79-84. Zhou Xingui,Cao Chengjie,Yuan Jiayin,et al.Methods and applications of quantitative prediction and evaluation of tectonic fracture in reservoir in petroliferous basin[J].Journal of Jilin University:Earth Science Edition,2004,34(1):79-84.
[20]	孙焕泉,王加滢.地下构造裂缝分布规律及其预测[J].大庆石油学院学报,2000,24(3):83-85. Sun Huanquan,Wang Jiaying.Distribution law of underground structural fissures and their forecasting[J].Journal of Daqing Petroleum Institute,2000,24(3):83-85.
[21]	Peacock D C P.The temporal relationship between joints and faults[J].Journal of Structural Geology,2001,23:329-341.
[22]	马旭杰,周文,唐瑜,等.川西新场地区须家河组二段气藏天然裂缝形成期次的确定[J].天然气工业,2013,33(8):15-19. Ma Xujie,Zhou Wen,Tang Yu,et al.Timing of natural fractures formed in the gas reservoirs of the 2nd member of Xujiahe Fm in the Xinchang area,western Sichuan Basin[J].Natural Gas Industry,2013,33(8):15-19.
[23]	崔效锋,胡幸平,俞春泉,等.汶川地震序列震源机制解研究[J].北京大学学报:自然科学版,2011,47(6):1063-1072. Cui Xiaofeng,Hu Xingping,Yu Chunquan,et al.Research on focal mechanism solutions of Wenchuan earthquake sequence[J].Acta Scientiarum Naturalium Universitatis Pekinensis,2011,47(6):1063-1072.
[24]	刘健,熊探宇,赵越,等.龙门山活动断裂带运动学特征及其构造意义[J].吉林大学学报:地球科学版,2012,42(S2):320-330. Liu Jian,Xiong Tanyu,Zhao Yue,et al.Kinematic characteristics of Longmenshan active fault zone and its tectonic implication[J].Journal of Jilin University:Earth Science Edition,2012,42(S2):320-330.
[25]	孟文,陈群策,吴满路,等.龙门山断裂带现今构造应力场特征及分段性研究[J].地球物理学进展,2013,28(3):1150-1160. Meng Wen,Chen Qunce,Wu Manlu,et al.Research on segmentation and characteristic of tectonic stress field of Longmenshan fault zone[J].Progress in Geophys,2013,28(3):1150-1160.
