东营凹陷坨庄地区T165油藏低压充注的流体包裹体记录

周振柱; 陈勇; 周瑶琪

doi:10.11781/sysydz201404473

东营凹陷坨庄地区T165油藏低压充注的流体包裹体记录

doi: 10.11781/sysydz201404473

1.
山东科技大学地球科学与工程学院, 山东青岛 266590
2. 中国石油大学(华东) 地球科学与技术学院, 山东青岛 266580

基金项目: 国家自然科学基金项目（41172111,40772082,40902040）资助。

详细信息

作者简介:
周振柱（1983—），男，讲师，从事油气成藏方面的研究。E-mail: zhouzhenzhu1983@163.com。

中图分类号: TE122.2⁺3
计量
- 文章访问数: 890
- HTML全文浏览量: 73
- PDF下载量: 737
- 被引次数: 0
出版历程
- 收稿日期: 2013-06-19
- 修回日期: 2014-06-17
- 刊出日期: 2014-07-28

Low-pressure accumulation of hydrocarbon recorded by fluid inclusions in T165 reservoir, Tuozhuang area, Dongying Sag

1.
College of Earth Science and Engineering, Shandong University of Science and Technology, Qingdao, Shandong 266590, China
2. School of Geosciences, China University of Petroleum, Qingdao, Shandong 266580, China

摘要

摘要: 东营凹陷坨庄地区深部储层中发育被方解石充填的构造裂缝，方解石脉中油气包裹体丰富。方解石脉中包含2种不同结晶形态的颗粒，它形细晶颗粒和自形中晶颗粒，且2种晶体颗粒中流体包裹体特征也有所差异。通过流体包裹体的镜下观察、显微测温以及PVT模拟恢复了包裹体被捕获时的温压条件，分析了油气成藏的特点:①流体包裹体只记录了一期油气成藏，主要在明化镇组沉积时期；②油气成藏早期，储层压力系数小于1，表现出低压成藏的特点，断层活动产生的泵吸作用是油气充注的主要动力。此外，研究结果表明，不能简单根据储层自生矿物的岩相学特征划分成藏期次。
- 油气包裹体 /
- 方解石脉 /
- 低压成藏 /
- 东营凹陷 /
- 渤海湾盆地
Abstract: Some fractures filled with calcites were found in the deep reservoirs in Tuozhuang area of the Dong-ying Sag. Large numbers of oil-bearing inclusions were contained in the calcite veins. The calcite veins contain two different morphologic crystals, which are fine xenomorphic crystal and medium-crystalline automorphic crystal, and the features of fluid inclusions in the two kinds of crystals are different. Based on optical observation, microthermometry and PVT simulation, this paper revealed the P-T trapping conditions of fluid inclusions, and also analyzed the characteristics of hydrocarbon accumulation. a) The fluid inclusions only recorded one period of accumulation, mainly during Nm. b) In the early accumulation, the pressure coefficient was less than 1, presenting the characteristic of low-pressure migration and injection. The seismic pumping caused by fault activities was the dominant dynamic force of hydrocarbon injection. In addition, it is not reliable to distinguish different accumulation periods by the petrographic characteristics of authigenetic minerals.
- hydrocarbon inclusion /
- calcite vein /
- low-pressure accumulation /
- Dongying Sag /
- Bohai Bay Basin

HTML全文

参考文献(23)

[1]	陈中红,査明,金强.东营凹陷超压系统的幕式排烃[J].石油与天然气地质,2004,25(4):444-447. Chen Zhonghong,Zha Ming,Jin Qiang.Episodic expulsion of hydrocarbons in overpressure systems in Dongying depression[J].Oil & Gas Geology,2004,25(4):444-447.
[2]	陈中红,査明.断陷湖盆超压封存箱形成机理与油气成藏机制:以渤海湾盆地东营凹陷为例[J].地质科学,2008,43(1):50-64. Chen Zhonghong,Zha Ming.Mechanism of over pressured fluid compartment and its controlling on hydrocarbon migration and accumulation in faulted lacustrine basin:A case study from the Dongying Sag,Bohai Bay Basin[J].Chinese Journal of Geology,2008,43(1):50-64.
[3]	邱楠生,金之钧.油气成藏的脉动式探讨[J].地学前缘,2000,7(4):561-567. Qiu Nansheng,Jin Zhijun.Study on pulse entrapment of hydrocarbon accumulation[J].Earth Science Frontiers,2000,7(4):561-567.
[4]	邱楠生,张善文,金之钧.东营凹陷油气流体运移模式探讨:来自沸腾包裹体的证据[J].石油实验地质,2001,23(4):403-407. Qiu Nansheng,Zhang Shanwen,Jin Zhijun.Migration models of hydrocarbon fluids in the Dongying depression:evidences from boiling fluid inclusions[J].Petroleum Geology & Experiment,2001,23(4):403-407.
[5]	邱楠生,金之钧,胡文瑄.东营凹陷油气充注历史的流体包裹体分析[J].石油大学学报:自然科学版,2000,24(4):95-103. Qiu Nansheng,Jin Zhijun,Hu Wenxuan.Study on the hydrocarbon charge history in Dongying Depression by evidence from fluid inclusions [J].Journal of the University of Petroleum,China:Edition of Natural Science,2000,24(4):95-103.
[6]	杜春国,邹华耀,邵振军,等.砂岩透镜体油气藏成因机理与模式[J].吉林大学学报:地球科学版,2006,36(3) 370-376. Du Chunguo,Zou Huayao,Shao Zhenjun,et al.Formation mechanism and mode of sand lens reservoir[J].Journal of Jilin University:Earth Science Edition,2006,36(3):370-376.
[7]	刘士林,郑和荣,林舸,等.渤海湾盆地东营凹陷异常压力分布和演化特征及与油气成藏关系[J].石油实验地质,2010,32(3):386-393. Liu Shilin,Zheng Herong,Lin Ge,et al.Distribution and evolution characteristics of abnormal pressure and its relationship with hydrocarbon accumulation in the Dongying sag of Bohai Bay basin[J].Petroleum Geology & Experiment,2010,32(3):386-393.
[8]	盛贤才,郭战峰.江汉平原簰深1井石炭系黄龙组流体包裹体特征及其地质意义[J].石油实验地质,2011,33(6):652-656. Sheng Xiancai,Guo Zhanfeng.Characteristics and geologic implication of fluid inclusions of Carboniferous Huanglong Formation in well Paishen 1,Jianghan Plain[J].Petroleum Geology & Experiment,2011,33(6):652-656.
[9]	陈顺勇,俞浩,林春明,等.下扬子黄桥地区龙潭组储层流体包裹体特征及油气成藏期研究[J].石油实验地质,2013,35(4):389-394. Chen Shunyong,Yu Hao,Lin Chunming,et al.Fluid inclusion features and hydrocarbon accumulation stages of Permian Longtan Formation,Huangqiao area,Lower Yangtze Basin[J].Petroleum Geology & Experiment,2013,35(4):389-394.
[10]	刘可禹,Bourder J,张宝收,等.应用流体包裹体研究油气成藏:以塔中奥陶系储集层为例[J].石油勘探与开发,2013,40(2):171-180. Liu Keyu,Bourdet J,Zhang Baoshou,et al.Hydrocarbon charge history of the Tazhong Ordovician reservoirs,Tarim Basin as revealed from an integrated fluid inclusion study[J].Petroleum Exploration and Development,2013,40(2):171-180.
[11]	Aplin A C,Macleod G,Larter S R,et al.Combined use of confocal Laser Microscopy and PVT simulation for estimating the composition and physical properties of petroleum in fluid inclusions[J].Marine and Petroleum Geology,1999,16:97-109.
[12]	Liu D H,Xiao X M,Mi J K,et al.Determination of trapping pressure and temperature of petroleum inclusions using PVT simulation software:a case study of Lower Ordovician carbonates from the Lunnan Low Uplift,Tarim Basin[J].Marine and Petroleum Geology,2003,20(1):29-43.
[13]	米敬奎,肖贤明,刘德汉,等.鄂尔多斯盆地上古生界储层中包裹体最小捕获压力的PVTsim模拟[J].地球化学,2002,31(4):402-406. Mi Jingkui,Xiao Xianming,Liu Dehan,et al.Simulation for minimum trapping pressure of inclusions occurring in Upper Paleozoic sandstone reservoir of Ordos Basin using PVTsim[J].Geochimica,2002,31(4):402-406.
[14]	Thiéry R,Pironon J,Walgenwitz F,et al.PIT (Petroleum Inclusion Thermodynamic):a new modeling tool for the characterization of hydrocarbon fluid inclusions from volumetric and microthermometric measurements[J].Journal of Geochemical Exploration,2000,69/70:701-704.
[15]	Thiéry R,Pironon J,Walgenwitz F.Fluid inclusions and PVTX modeling:examples from the Garn formation in well 6507 2/2,Haltenbanken,Mid-Norway[J].Marine and Petroleum Geology,2002,19(6):755-765.
[16]	Thiéry R,Pironon J,Walgenwitz F,et al.Individual characterization of petroleum inclusions (composition and P-T trapping conditions) by microthermometry and confocal scanning laser microscopy:inferences from applied thermodynamics of oils [J].Marine and Petroleum Geology,2002,19(7):847-859.
[17]	Grimmer J O W,Pironon J,Teinturier S,et al.Recognition and differentiation of gas condensates and other oil types using microthermometry of petroleum inclusions[J].Journal of Geoche-mical Exploration,2003,78/79:367-371.
[18]	张鼐,张水昌,李新景,等.塔中117井储层烃包裹体研究及油气成藏史[J].岩石学报,2005,21(5):1473-1478. Zhang Nai,Zhang Shuichang,Li Xinjing,et al.Integrated hydrocarbon inclusion studies and oil charge history in the well Tazhong117,Tarim basin[J].Acta Petrologica Sinica,2005,21(5):1473-1478.
[19]	Teinturier S,Pironon J.Experimental growth of quartz in petroleum environment.part I:Procedures and fluid trapping[J].Geochimica et Cosmochimica Acta,2004,68(11):2495-2507.
[20]	陈红汉,董伟良,张树林,等.流体包裹体在古压力模拟研究中的应用[J].石油与天然气地质,2002,23(3):207-211. Chen Honghan,Dong Weiliang,Zhang Shulin,et al.Application of fluid inclusion in palaeopressure modelling research[J].Oil & Gas Geology,2002,23(3):207-211.
[21]	孙秀丽,陈红汉,宋国奇,等.东营凹陷胜坨地区深层油气成藏期及其主控因素分析[J].石油学报,2010,31(3):386-393. Sun Xiuli,Chen Honghan,Song Guoqi,et al.Hydrocarbon accumulation period and its controlling factors in deep formations of Shengtuo area in Dongying Depression[J].Acta Petrolei Sinica,2010,31(3):386-393.
[22]	华保钦.构造应力场、地震泵和油气运移[J].沉积学报,1995,13(2):77-85. Hua Baoqin.Stress field,seismic pumping and oil-gas migration[J].Acta Sedimentologica Sinica,1995,13(2):77-85.
[23]	阎福礼,贾东,卢华复,等.东营凹陷油气运移的地震泵作用[J].石油与天然气地质,1999,20(4):295-298. Yan Fuli,Jia Dong,Lu Huafu,et al.Seismic pumping mechanism of hydrocarbon migration in Dongying Depression[J].Oil & Gas Geology,1999,20(4):295-298.
