羌塘盆地南部布曲组含油白云岩中自生文石胶结物的鉴定及其成因探讨

张帅; 伊海生; 夏国清; 梁定勇

doi:10.11781/sysydz201606772

羌塘盆地南部布曲组含油白云岩中自生文石胶结物的鉴定及其成因探讨

doi: 10.11781/sysydz201606772

张帅¹,
伊海生^2,3, ,,
夏国清³,
梁定勇⁴

1.
成都理工大学地球科学学院, 成都 610059
2. 油气藏地质及开发工程国家重点实验室, 成都 610059
3. 成都理工大学沉积地质研究院, 成都 610059
4. 海南省地质调查院, 海口 570226

基金项目: 国家自然科学基金（41572089）和国土资源部沉积盆地与油气资源重点实验室开放基金（zdsys2014002）资助。

详细信息

作者简介:
张帅(1985-),男,博士研究生,从事储层矿物岩石学研究。E-mail:zsdolomite@gmail.com。

通讯作者:
伊海生(1959-),男,教授,博士生导师,从事沉积地质学教学和科研工作。E-mail:yhs@cdut.edu.cn。

中图分类号: TE122.2
计量
- 文章访问数: 1201
- HTML全文浏览量: 103
- PDF下载量: 304
- 被引次数: 0
出版历程
- 收稿日期: 2015-12-10
- 修回日期: 2016-08-25
- 刊出日期: 2016-11-28

Mineral and genesis study of authigenic aragonite in sucrosic dolomites from Middle Jurassic Buqu Formation in southern Qiangtang Basin, Tibet

1.
School of Earth Science, Chengdu University of Technology, Chengdu, Sichuan 610059, China
2. State Key Laboratory of Oil/Gas Reservoir Geology and Exploitation, Chengdu, Sichuan 610059, China
3. Institute of Sedimentary Geology, Chengdu University of Technology, Chengdu, Sichuan 610059, China
4. Hainan Institute of Geological Survey, Haikou, Hainan 570226, China

摘要

摘要: 在羌塘盆地南部隆鄂尼地区中侏罗统布曲组砂糖状白云岩中首次发现针柱状胶结物，分布于沥青充填的溶蚀孔隙中。显微结构、微区X射线衍射以及电子探针分析表明，胶结物类型为自生文石，呈针柱状晶形，簇状、放射状集合体，MgO和SrO质量分数呈正相关。微区同位素测试显示，文石胶结物δ¹³C_PDB值为3.5‰~3.98‰，δ¹⁸O_PDB值介于-11.63‰~-9.98‰。文石在地质历史时期形成的碳酸盐岩中很少发现，常通过新生变形作用或溶解作用转变为低镁方解石。砂糖状白云岩中自生文石碳氧同位素组成与现代海洋沉积和大气淡水成因的文石存在较大差异，其形成过程中淡水淋滤作用影响较小，δ¹⁸O值的负偏主要受埋藏期地温梯度控制。储层成岩序列显示文石胶结物形成于埋藏白云石化作用之后，有机酸溶蚀伴随着碳酸钙自生矿物沉淀，烃类充注抑制了文石向方解石的转化。文石胶结物形成于晚成岩阶段，属于埋藏环境下碳酸盐矿物溶解再沉淀的产物，烃类充注可能对文石的保存起重要的控制作用。
- 文石 /
- 微区X射线衍射 /
- 碳氧同位素 /
- 中侏罗统 /
- 羌塘盆地
Abstract: Columnar-acicular cement has been discovered in the Middle Jurassic Buqu Formation of Longeni area in the southern Qiangtang Basin of Tibet, distributed in saccharoidal dolomite in dissolution pores filled with bitumen. As demonstrated by microstructure, in situ X-ray diffraction (XRD) and electron microprobe analysis (EMPA), mineralogical investigations have confirmed the emergence of authigenic aragonite. It occurs as bundles and radiating clusters consisting of needle crystals. Major elements show that MgO and SrO have a positive correlation. In situ isotopic analysis indicates that δ¹³C values range from 3.5‰PDB to 3.98‰PDB and δ¹⁸O ranges from -9.98‰PDB to -11.63‰PDB. Aragonite is rarely found in carbonate rocks formed during geological times because of the conversion of aragonite to low-Mg-calcite through neomorphism or dissolution. Oxygen and carbon isotopic composition of aragonite cements in saccharoidal dolomite has greater variability compared with aragonite formed in modern marine or meteoric diagenesis. In the formation process meteoric water leaching has less influence and a negative excursion of δ¹⁸O is mainly controlled by geothermal gradient during burial. The reservoir diagenetic sequence shows that aragonite cements formed after burial dolomitization. Authigenic mineral precipitates with organic acid dissolution, and hydrocarbon filling has largely inhibited the conversion of aragonite to calcite. The comprehensive analysis suggests that aragonite cements were precipitated from a dissolution-reprecipitation process of carbonate minerals during late diagenesis. Hydrocarbon filling played an important role controlling the preservation of aragonite cements.
- aragonite /
- micro X-ray diffraction /
- carbon and oxygen isotopes /
- Middle Jurassic /
- Qiangtang Basin

HTML全文

参考文献(40)

[1]	曾允孚,夏文杰.沉积岩石学[M].北京:地质出版社,1986:158-168. Zeng Yunfu,Xia Wenjie.Sedimentary petrology[M].Beijing:Geo-logy Publishing House,1986:158-168.
[2]	Mazzullo S J.Calcite pseudospar replacive of marine acicular aragonite,and implications for aragonite cement diagenesis[J].Journal of Sedimentary Research,1980,50(2):409-422.
[3]	Wilkinson B H,Owen R M,Carroll A R.Submarine hydrothermal weathering,global eustasy,and carbonate polymorphism in Pha-nerozoic marine oolites[J].Journal of Sedimentary Research,1985,55(2):171-183.
[4]	Grammer G M,Ginsburg R N,Swart P K,et al.Rapid growth rates of syndepositional marine aragonite cements in steep marginal slope deposits,Bahamas and Belize[J].Journal of Sedimentary Research,1993,63(5):983-989.
[5]	Adabi M H.A re-evaluation of aragonite versus calcite seas[J].Carbonates and Evaporites,2004,19(2):133-141.
[6]	赵希涛,沙庆安,冯文科.海南岛全新世海滩岩[J].地质科学,1978,13(2):163-173. Zhao Xitao,Sha Qing'an,Feng Wenke.Holocene beachrocks at Hainan island[J].Chinese Journal of Geology,1978,13(2):163-173.
[7]	Delaney M L,Linn L J,Davies P J.Trace and minor element ratios in Halimeda aragonite from the Great Barrier Reef[J].Coral Reefs,1996,15(3):181-189.
[8]	Frank T D,Titschack J,Thierens M.Aragonite loss in a cold-water coral mound:Mechanisms and implications[J].Sedimentology,2011,58(3):670-690.
[9]	张河清.川中侏罗系大安寨组中保存的骨骼文石[J].天然气工业,1984,4(1):22-26. Zhang Heqing.Skeletal aragonite preserved in Daanzhai limestone of Jurassic, central Sichuan[J].Natural Gas Industry,1984,4(1):22-26.
[10]	Brachert T C,Dullo W C.Shallow burial diagenesis of skeletal carbonates:Selective loss of aragonite shell material (Miocene to recent,Queensland Plateau and Queensland Trough,NE Australia):Implications for shallow cool-water carbonates[J].Sedimentary Geology,2000,136(3/4):169-187.
[11]	Aissaoui D M.Botryoidal aragonite and its diagenesis[J].Sedi-mentology,1985,32(3):345-361.
[12]	林玉石,黄新耀,张美良,等.中国南方发现大型文石笋[J].地学前缘,2007,14(2):236-241. Lin Yushi,Huang Xinyao,Zhang Meiliang,et al.Large aragonite stalagmites found in South China[J].Earth Science Frontiers,2007,14(2):236-241.
[13]	张海伟,蔡演军,谭亮成.石笋矿物类型、成因及其对气候和环境的指示[J].中国岩溶,2010,29(3):222-228. Zhang Haiwei,Cai Yanjun,Tan Liangcheng.Phase composition and formation of stalagmite minerals:Indications of climate and environment[J].Carsologica Sinica,2010,29(3):222-228.
[14]	Lachniet M S,Bernal J P,Asmerom Y,et al.Uranium loss and aragonite-calcite age discordance in a calcitized aragonite stalagmite[J].Quaternary Geochronology,2012,14:26-37.
[15]	赵文俞,刘嵘,王勤燕,等.木兰山蓝片岩中两种文石的产出特征及其动力学意义[J].地球科学(中国地质大学学报),2001,26(6):568-573. Zhao Wenyu,Liu Rong,Wang Qinyan,et al.Aragonite from Mulan-shan glaucophane schist:Implications for regional evolution of south-western Dabie Mountains,central China[J].Earth Science(Journal of China University of Geosciences),2001,26(6):568-573.
[16]	邱海峻,许志琴,张泽明,等.苏北高压变质带绿片岩中石榴石内文石包裹体的发现[J].地质通报,2002,21(10):617-624. Qiu Haijun,Xu Zhiqin,Zhang Zeming,et al.New mineral evidence of high-pressure metamorphism of the Subei high-pressure belt:Aragonite inclusions in garnet from greenschist[J].Geological Bulletin of China,2002,21(10):617-624.
[17]	戈莹.四川会理的文石晶体[J].矿物岩石,1992,12(1):8-11. Ge Ying.A study on aragonite from Huili,Sichuan province[J].Mineralogy and Petrology,1992,12(1):8-11.
[18]	武永强,潘永信.太原西山奥陶系文石的成因[J].山西矿业学院学报,1995,13(1):23-29. Wu Yongqiang,Pan Yongxin.Origin of aragonite in Ordovician carbonates of Taiyuan Xishan[J].Shanxi Mining Institute Learned Journal,1995,13(1):23-29.
[19]	Sandberg P.Aragonite cements and their occurrence in ancient limestones[M]//Schneidermann N,Harris P M.Carbonate Cements.[s.l.]:SEPM Special Publications,1985,36:33-57.
[20]	王成善,伊海生,刘池洋,等.西藏羌塘盆地古油藏发现及其意义[J].石油与天然气地质,2004,25(2):139-143. Wang Chengshan,Yi Haisheng,Liu Chiyang,et al.Discovery of paleo-oil-reservoir in Qiangtang Basin in Tibet and its geological significance[J].Oil & Gas Geology,2004,25(2):139-143.
[21]	秦建中.青藏高原羌塘盆地油气资源潜力分析[J].石油实验地质,2006,28(6):566-573. Qin Jianzhong.Study on the petroleum resource potential in the Qiangtang Basin,Qinghai-Tibet Plateau[J].Petroleum Geology & Experiment,2006,28(6):566-573.
[22]	南征兵,李永铁,郭祖军.羌塘盆地油气显示及油源对比[J].石油实验地质,2008,30(5):503-507. Nan Zhengbing,Li Yongtie,Guo Zujun.Hydrocarbon show and correlation between oil and source rock in the Qiangtang Basin[J].Petroleum Geology & Experiment,2008,30(5):503-507.
[23]	张立强,纪友亮,李永铁.羌塘盆地侏罗系白云岩储层特征研究[J].石油实验地质,2001,23(4):384-389. Zhang Liqiang,Ji Youliang,Li Yongtie.Reservoir characteristics of the Jurassic dolomite in the Qiangtang Basin[J].Petroleum Geology & Experiment,2001,23(4):384-389.
[24]	伊海生,高春文,张小青,等.羌塘盆地双湖地区古油藏白云岩储层的显微成岩组构特征及意义[J].成都理工大学学报(自然科学版),2004,31(6):611-615. Yi Haisheng,Gao Chunwen,Zhang Xiaoqing,et al.Microscopic diagenetic fabrics of dolomite reservoir from Shuanghu paleo-oil pool of Qiangtang Basin and its petroleum exploration implications[J].Journal of Chengdu University of Technology(Science & Technology Edition),2004,31(6):611-615.
[25]	刘建清,杨平,陈文彬,等.羌塘盆地中央隆起带南侧隆额尼-昂达尔错布曲组古油藏白云岩特征及成因机制[J].地学前缘,2010,17(1):311-321. Liu Jianqing,Yang Ping,Chen Wenbin,et al.The characteristics of Longeni-Angdaercuo paleo-oil dolomite in southern part of the central uplift zone of Qiangtang Basin and its forming mechanism[J].Earth Science Frontiers,2010,17(1):311-321.
[26]	伊海生,陈志勇,季长军,等.羌塘盆地南部地区布曲组砂糖状白云岩埋藏成因的新证据[J].岩石学报,2014,30(3):737-746. Yi Haisheng,Chen Zhiyong,Ji Changjun,et al.New evidence for deep burial origin of sucrosic dolomites from Middle Jurrasic Buqu Formation in southern Qiangtang Basin[J].Acta Petrolo-gica Sinica,2014,30(3):737-746.
[27]	陈明,王剑,谭富文,等.藏北北羌塘坳陷中西部地区布曲组碳酸盐岩烃源岩分布特征[J].石油实验地质,2010,32(2):181-185. Chen Ming,Wang Jian,Tan Fuwen,et al.The distributed characte-ristic of middle Jurassic Buqu Formation carbonate source rock in midwest area of north Qiangtang Depression[J].Petroleum Geology & Experiment,2010,32(2):181-185.
[28]	何道清.碳酸盐岩碳、氧同位素分析激光微取样技术[J].西南石油学院学报,2003,25(1):12-15. He Daoqing.The laser micro-sampling technique for analysis of C and O isotope in carbonate[J].Journal of Southwest Petro-leum Institute,2003,25(1):12-15.
[29]	肖平,陆琦,于吉顺.采用X射线粉晶衍射仪实现岩石薄片中矿物的原位微区分析[J].矿物岩石,2014,34(1):6-9. Xiao Ping,Lu Qi,Yu Jishun.Using X-Ray powder diffractometer to analyze in situ diffraction for mineral in rock thin section[J].Journal of Mineralogy and Petrology,2014,34(1):6-9.
[30]	Frisia S,Borsato A,Fairchild I J,et al.Aragonite-calcite relationships in speleothems (Grotte de Clamouse,France):Environment,fabrics,and carbonate geochemistry[J].Journal of Sedimentary Research,2002,72(5):687-699.
[31]	张海伟,蔡演军,安芷生,等.石笋矿物由文石转变为方解石后碳、氧同位素组成的变化[J].矿物岩石地球化学通报,2014,33(1):31-37. Zhang Haiwei,Cai Yanjun,An Zhisheng,et al.Variation of oxygen and carbon isotope compositions in transformation of speleothem primary aragonite to secondary calcite[J].Bulletin of Mineralogy,Petrology and Geochemistry,2014,33(1):31-37.
[32]	Kimbell T N,Humphrey J D.Geochemistry and crystal morphology of aragonite cements of mixing-zone origin,Barbados,West-Indies[J].Journal of Sedimentary Research,1994,64(3a):604-614.
[33]	Allan J R,Wiggins W D.Dolomite reservoirs:Geochemical techniques for evaluating origin and distribution[M].Tulsa:American Association of Petroleum Geologists,1993.
[34]	张秀莲.碳酸盐岩中氧、碳稳定同位素与古盐度、古水温的关系[J].沉积学报,1985,3(4):17-30. Zhang Xiulian.Relationship between carbon and oxygen stable isotope in carbonate rocks and paleosalinity and paleotemperature of seawater[J].Acta Sedimentologica Sinica,1985,3(4):17-30.
[35]	周根陶,郑永飞.文石-水体系氧同位素分馏系数的低温实验研究[J].高校地质学报,2000,6(1):89-105. Zhou Gentao,Zheng Yongfei.Experimental studies of oxygen isotope fractionation factors between aragonite and water at low temperatures[J].Geological Journal of China Universities,2000,6(1):89-105.
[36]	王兴涛,张庆石,张吉,等.青藏高原中生界白云岩特征研究及成因分析[J].沉积学报,2000,18(4):555-559. Wang Xingtao,Zhang Qingshi,Zhang Ji,et al.Character study and analysis of dolomite of Mesozoic in Qingzang Plateau[J].Acta Sedimentologica Sinica,2000,18(4):555-559.
[37]	张小青.羌塘盆地双湖地区侏罗系白云岩成因及储集性研究[D].成都:成都理工大学,2005. Zhang Xiaoqing.Study on the genesis and reservoir characteristics of Jurassic dolomites in Shuanghu area,Qiangtang Basin[D].Chengdu:Chengdu University of Technology,2005.
[38]	佘敏,寿建峰,沈安江,等.从表生到深埋藏环境下有机酸对碳酸盐岩溶蚀的实验模拟[J].地球化学,2014,43(3):276-286. She Min,Shou Jianfeng,Shen Anjiang,et al.Experimental simulation of dissolution for carbonate rocks in organic acid under the conditions from epigenesis to deep burial environments[J].Geochimica,2014,43(3):276-286.
[39]	Dodd J R.Processes of conversion of aragonite to calcite with exa-mples from the Cretaceous of Texas[J].Journal of Sedimentary Research,1966,36(3):733-741.
[40]	Wendt J.Aragonite in Permian reefs[J].Nature,1977,267(5609):335-337.
