塔里木盆地巴楚地区寒武系肖尔布拉克组储层特征及成因模式

李斌; 彭军; 杨素举; 夏青松; 徐勤琪; 郝悦琪

doi:10.11781/sysydz201706797

塔里木盆地巴楚地区寒武系肖尔布拉克组储层特征及成因模式

doi: 10.11781/sysydz201706797

1.
西南石油大学地球科学与技术学院, 成都 610500
2. 西南石油大学油气藏地质及开发工程国家重点实验室, 成都 610500
3. 中国石化西北油田分公司勘探开发研究院, 乌鲁木齐 830011

基金项目: 油气藏地质及开发工程国家重点实验室基金（PLN201616）和"构造与油气资源"教育部重点实验室基金（TPR-2013-16）资助。

详细信息

作者简介:
李斌(1977-),男,博士,副教授,从事油气成藏的教学和科研工作。E-mail:lbin@swpu.edu.cn。

中图分类号: TE122.2
计量
- 文章访问数: 1260
- HTML全文浏览量: 140
- PDF下载量: 333
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-07
- 修回日期: 2017-09-10
- 刊出日期: 2017-11-28

Genetic model and characteristics of the Cambrian Shorebulake reservoir in Bachu area, Tarim Basin

1.
School of Geoscience and Technology, Southwest Petroleum University, Chengdu, Sichuan 610500, China
2. State Key Laboratory of Oil and Gas Reservoir Geology and Exploration, Southwest Petroleum University, Chengdu, Sichuan 610500, China
3. Research Institute of Petroleum Exploration and Production, SINOPEC Northwest Company, Urumqi, Xinjiang 830011, China

摘要

摘要: 针对塔里木盆地巴楚地区肖尔布拉克组储层研究较为薄弱的问题，通过多口井岩心观察、薄片鉴定和地化分析，认为该区肖尔布拉克组主要发育晶粒白云岩和泥微晶白云岩，储层物性受岩石结构控制明显，其中细晶白云岩及粉晶白云岩孔渗性能最好。肖尔布拉克组储层储集空间以晶间孔、溶蚀孔洞和裂缝为主，整体上属于低排驱压力细-中孔喉道型，储集性能较好。储层经历多种白云石化作用改造，以埋藏白云石化作用为主，受一定热液作用影响。储层受喜马拉雅期构造作用影响较大，破裂形成的裂缝沟通残余孔隙，多期酸性流体渗入叠加改造，一定程度上增加了储集空间，形成现今优质储层。综合认为巴楚隆起肖尔布拉克组储层在多期构造断裂叠加区域储集能力最好。
- 成因模式 /
- 白云石化 /
- 储层特征 /
- 肖尔布拉克组 /
- 巴楚地区 /
- 塔里木盆地
Abstract: Knowledge of the Cambrian Shorebulake reservoirs in the Bachu area of Tarim Basin is limited at present. Core and microscopic observations as well as geochemical analyses showed that grain dolomites and microcrystalline dolomites are common in the Shorebulake Formation. Reservoir physical properties were obviously influenced by rock structure, and the porosity and permeability of fine-grained and powdery dolomites are the best. The reservoir space in the Shorebulake Formation was mainly composed of intergranular pores, dissolution holes and fractures, with low discharge pressure and fine to medium pore-throats, showing a good reservoir capacity. The diagenetic transformation of the reservoir was dominated by buried dolomitization, and partially affected by hydrothermal activity. The Himalayan movement added fractures to the study area, which enhanced communication of residual pores and helped acid fluid transform reservoirs, increasing reservoir volume to a certain extent and resulting in the present favorable reservoirs. The superimposed area of multi-phase tectonic fractures is considered as a favorable place for the Shorebulake reservoir in the Bachu uplift.
- genetic model /
- dolomitization /
- reservoir feature /
- Shorebulake Formation /
- Bachu area /
- Tarim Basin

HTML全文

参考文献(23)

[1]	何洧.塔里木盆地巴楚地区寒武系储层特征及主控因素[D].成都:成都理工大学,2013. He Wei.Research on reservoir characterization and key controlling factors of Cambrian reservoir in Bachu region of Tarim Basin[D].Chengdu:Chengdu University of Technology,2013.
[2]	杨永剑,刘家铎,田景春,等.巴楚隆起寒武系层序格架及生储盖组合特征[J].西南石油大学学报(自然科学版),2011,33(4):53-58. Yang Yongjian,Liu Jiaduo,Tian Jingchun,et al.The Cambrian sequence stratigraphy framework and source-reservoir-cap rock association of Bachu uplift in Tarim Basin[J].Journal of Southwest Petroleum University (Science & Technology Edition),2011,33(4):53-58.
[3]	焦存礼,邢秀娟,何碧竹,等.塔里木盆地下古生界白云岩储层特征与成因类型[J].中国地质,2011,38(4):1008-1015. Jiao Cunli,Xing Xiujuan,He Bizhu,et al.Characteristics and genetic types of Cambrian-Ordovician dolomite reservoirs in Tarim Basin[J].Geology in China,2011,38(4):1008-1015.
[4]	蔡习尧,李越,钱一雄,等.塔里木板块巴楚隆起区寒武系盐下勘探潜力分析[J].地层学杂志,2010,34(3):283-288. Cai Xiyao,Li Yue,Qian Yixiong,et al.Exploration potential of the salt-capped Cambrian strata in the Bachu high,Tarim block,NW China[J].Journal of Stratigraphy,2010,34(3):283-288.
[5]	陈国俊,王琪,孟自芳,等.塔里木盆地西部寒武-奥陶系储层分布特征[J].新疆地质,2002,20(S1):91-95. Chen Guojun,Wang Qi,Meng Zifang,et al.Distribution of Cambrian-Ordovician reservoir rocks controllded by sequence stratigraphy in western Tarim Basin[J].Xinjiang Geology,2002,20(S1):91-95.
[6]	杜金虎,潘文庆.塔里木盆地寒武系盐下白云岩油气成藏条件与勘探方向[J].石油勘探与开发,2016,43(3):327-339. Du Jinhu,Pan Wenqing.Accumulation conditions and play targets of oil and gas in the Cambrian subsalt dolomite,Tarim Basin,NW China[J].Petroleum Exploration and Development,2016,43(3):327-339.
[7]	熊益学,陈永权,关宝珠,等.塔里木盆地下寒武统肖尔布拉克组北部台缘带展布及其油气勘探意义[J].沉积学报,2015,33(2):408-415. Xiong Yixue,Chen Yongquan,Guan Baozhu,et al.Distribution of northern platform margin and implications to favorable exploration regions on Lower Cambrian Xiaoerbulake Formation,Tarim Basin[J].Journal of Sedimentology,2015,33(2):408-415.
[8]	黄太柱,蒋华山,马庆佑.塔里木盆地下古生界碳酸盐岩油气成藏特征[J].石油与天然气地质,2014,35(6):780-787. Huang Taizhu,Jiang Huashan,Ma Qingyou.Hydrocarbon accumulation characteristics in Lower Paleozoic Carbonate reservoirs of Tarim Basin[J].Oil & Gas Geology,2014,35(6):780-787.
[9]	刘伟,黄擎宇,王坤,等.深埋藏阶段白云岩化作用及其对储层的影响:以塔里木盆地下古生界白云岩为例[J].天然气地球科学,2016,27(5):772-779. Liu Wei,Huang Qingyu,Wang Kun,et al.Dolomization and influence on reservoir development in deep-burial stage:A case study of Lower Paleozoic in Tarim Basin[J].Natural Gas Geoscience,2016,27(5):772-779.
[10]	黄擎宇,刘迪,叶宁,等.塔里木盆地寒武系白云岩储层特征及成岩作用[J].东北石油大学学报,2013,37(6):63-74. Huang Qingyu,Liu Di,Ye Ning,et al.Reservoir characteristics and diagenesis of the Cambrian dolomite in Tarim Basin[J].Journal of Northeast Petroleum University,2013,37(6):63-74.
[11]	陈文玲,罗平,单钰铭.塔里木苏盖特布拉克地区肖尔布拉克组白云岩储层特征分析[J].石油地质与工程,2010,24(1):12-15. Chen Wenling,Luo Ping,Shan Yuming.Characteristics analysis of Xiaorbulak Formation dolomite rock reservoir in Tarim Sugetbulak area[J].Petroleum Geology and Engineering,2010,24(1):12-15.
[12]	陈永权,周新源,杨文静,等.塔里木盆地寒武系白云岩的主要成因类型及其储层评价[J].海相油气地质,2009,14(4):10-17. Chen Yongquan,Zhou Xinyuan,Yang Wenjing,et al.Genesis of Cambrian dolostone and the reservoir evaluation in Tarim Basin[J].Marine Origin Petroleum Geology,2009,14(4):10-17.
[13]	汤朝阳,王敏,姚华舟,等.白云岩石化作用及白云岩问题研究述评[J].华东理工学院学报,2006,29(3):205-210. Tang Zhaoyang,Wan Min,Yao Huazhou,et al.Current topics about dolomitization and the problem of dolostones[J].Journal of East China Institute of Technology,2006,29(3):205-210.
[14]	蔺军,周芳芳,袁国芬.塔河地区寒武系储层深埋藏白云石化特征析[J].石油与天然气地质,2010,31(1):13-21. Lin Jun,Zhou Fangfang,Yuan Guofen.Features of deep-burial dolomitization of the Cambrian reservoirs in Tahe region[J].Oil & Gas Geology,2010,31(1):13-21.
[15]	孟祥豪.塔河深层寒武系优质储层特征及形成机理研究[D].成都:成都理工大学,2012. Meng Xianghao.A research of the deep Cambrian high-quality reservoir characteristics and formation mechanism in Tahe area[D].Chengdu:Chengdu University of Technology,2012.
[16]	黄擎宇.塔里木盆地中央隆起区寒武-奥陶系白云石化作用及白云岩储层成因研究[D].成都:成都理工大学,2014. Huang Qingyu.Dolomitization and origin of the Cambrian-Ordovician dolomite reservoirs in the central uplift,Tarim BasiZ[D].Chengdu:Chengdu University of Technology,2014.
[17]	邵小明,文山师,刘存革,等.塔河油田下寒武统肖尔布拉克组构造控制热液白云岩储层分布与勘探前景[J].地质科技情报,2017,36(2):146-150. Shao Xiaoming,Wen Shanshi,Liu Cunge,et al.Distribution and exploration prospect of structurally controlled hydrothermal dolomite reservoir in Xiaoerbulake Formation of Lower Cambrian,Tahe Oilfield[J].Geological Science and Technology Information,2017,36(2):146-150.
[18]	李庆,胡文瑄,钱一雄,等.塔里木盆地肖尔布拉克组溶蚀型白云岩储层发育特征[J].石油与天然气地质,2011,32(4):522-530. Li Qing,Hu Wenxuan,Qian Yixiong,et al.Features of dissolved dolostone reservoirs in the Xiaoerbulak Formation,Tarim Basin[J].Oil & Gas Geology,2011,32(4):522-530.
[19]	周波,李明,段书府,等.巴楚地区寒武系碳酸盐岩白云石化机制[J].石油勘探与开发,2012,39(2):198-202. Zhou Bo,Li Ming,Duan Shufu,et al.Dolomitization mechanism of Cambrian carbonates in the Bachu area Tarim Basin,NW China[J].Petroleum Exploration and Development,2012,39(2):198-202.
[20]	倪新峰,陈永权,朱永进,等.塔北地区寒武纪深层白云岩构造-岩相古地理特征及勘探方向[J].岩性油气藏,2015,27(5):135-143. Ni Xinfeng,Chen Yongquan,Zhu Yongjin,et al.Tectonic-lithofacies palaeogeography characteristics of Cambrian deep dolomite and exploration prospects in northern Tarim Basin[J].Lithologic Re-servoirs,2015,27(5):135-143.
[21]	何宏,彭苏萍,邵龙义,等.巴楚隆起与阿瓦提凹陷寒武系及奥陶系沉积古地理分析[J].煤田地质与勘探,2002,30(6):1-4. He Hong,Peng Suping,Shao Longyi,et al.Sedimentology and palaeogeography of the Cambrian-Ordovician in Bachu Uplift and Awati Depression,the Tarim Basin[J].Coal Geology & Exploration,2002,30(6):1-4.
[22]	郑剑锋,沈安江,刘永福,等.塔里木盆地寒武系与蒸发岩相关的白云岩储层特征及主控因素[J].沉积学报,2013,31(1):89-98. Zheng Jianfeng,Shen Anjiang,Liu Yongfu,et al.Main Contro-lling factors and characteristics of Cambrian dolomite reservoirs related to evaporite in Tarim Basin[J].Acta Sedimentologica Cinica,2013,31(1):89-98.
[23]	王坤,胡素云,胡再元,等.塔里木盆地古城地区寒武系热液作用及其对储层发育的影响[J].石油学报,2016,37(4):439-453. Wang Kun,Hu Suyun,Hu Zaiyuan,et al.Cambrian hydrothermal action in Gucheng area,Tarim Basin and its influences on reservoir development[J].Acta Petrolei Sinica,2016,37(4):439-453.
