下扬子地区中上二叠统页岩有机孔发育特征

曹涛涛; 邓模; 罗厚勇; 刘虎; 刘光祥; HURSTHOUSE Andrew Stefan

doi:10.11781/sysydz201803315

下扬子地区中上二叠统页岩有机孔发育特征

doi: 10.11781/sysydz201803315

1.
湖南科技大学页岩气资源利用与开发湖南省重点实验室, 湖南湘潭 411201
2. 中国石化石油勘探开发研究院无锡石油地质研究所, 江苏无锡 214126
3. 页岩气评价与开采四川省重点实验室, 成都 600091

基金项目: 国家科技重大专项“彭水地区常压页岩气勘探开发示范工程”（2016ZX05061）和国家自然科学基金“页岩解析气碳同位素分馏特征及其指示意义”（41503033）联合资助。

详细信息

作者简介:
曹涛涛(1987-),男,博士,讲师,从事页岩气地质研究工作。E-mail:515165359@163.com。

中图分类号: TE122.2
计量
- 文章访问数: 1661
- HTML全文浏览量: 207
- PDF下载量: 231
- 被引次数: 0
出版历程
- 收稿日期: 2017-08-30
- 修回日期: 2018-03-19
- 刊出日期: 2018-05-28

Characteristics of organic pores in Middle and Upper Permian shale in the Lower Yangtze region

1.
Hunan Provincial Key Laboratory of Shale Gas Resource Utilization, Hunan University of Science and Technology, Xiangtan, Hunan 411201, China
2. Wuxi Research Institute of Petroleum Geology, SINOPEC, Wuxi, Jiangsu 214126, China
3. Sichuan Key Laboratory of Shale Gas Evaluation and Exploration, Chengdu, Sichuan 600091, China

摘要

摘要: 下扬子地区中上二叠统发育一套海陆过渡相页岩，其显微组成与海相页岩存在明显的差异，为了研究该套页岩有机孔的发育特征及影响因素，开展了有机岩石学、扫描电镜、氩离子抛光扫描电镜、气测孔隙度和压汞等相关分析。研究表明，中上二叠统页岩中有机孔整体发育较好，但不同有机质组分中孔隙的发育存在明显的差别，具体表现为镜质体内孔隙发育差，固体沥青内发育少量孤立的孔隙，腐泥质内具有丰富的孔隙。黄铁矿或黏土矿物常与有机质形成有机/矿物复合体，复合体内有机孔普遍发育较好，可能与黄铁矿或黏土矿物促进有机质生烃和分解有关。中上二叠统页岩TOC含量与比表面积之间存在明显的线性正相关性，但与孔隙度之间具有复杂的关系，当w（TOC）<6.16%时，孔隙度随TOC含量的增加而增加，而当w（TOC）>6.16%时，孔隙度普遍较低且与TOC含量之间存在微弱的负相关性。孔径分布特征也揭示高TOC页岩的中—大孔体积明显低于低TOC页岩。页岩孔隙结构发育特征表明，TOC含量越高、固体沥青组分以及贫氢组分的含量越高，这些组分占据的矿物孔隙越多，降低了页岩总的孔隙空间，且TOC含量越高，页岩越易被压实，造成中大孔塌陷，进一步降低了页岩的孔隙度。
- 有机孔 /
- 孔隙度 /
- 孔径分布 /
- 显微组成 /
- 页岩 /
- 中上二叠统 /
- 下扬子地区
Abstract: A set of transitional shale reservoirs developed in the Middle and Upper Permian strata in the Lower Yangtze region, with a maceral composition significantly different from that of marine shale. Organic petrology, scanning electron microscopy, field emission scanning electron microscopy in combination with argon ion polishing, gas-filled porosity and mercury intrusion experiments were conducted in order to reveal the characteristics of organic pores and their influencing factors. The results showed that organic pores were well developed overall in the Middle and Upper Permian shale, but have significantly different characteristics in different maceral grains. Vitrinite generally has no or rare pores developed, solid bitumen could produce a small quantity of large-scale isolated pores, and sapropelinite usually contains a large number of small pores, which is the main contributor to organic porosity. Pyrite and/or clay minerals could be mixed with organic matter and then enhance the development of pores in organic matter grains, which may be related to the effect of pyrite and clay minerals on organic matter generation and decomposition. Although there is a positive relationship between specific surface area and TOC content, the relationship of porosity with TOC content is rather complex. The TOC content has a positive relationship with porosity for the Middle and Upper Permian shale when w(TOC)<6.16%, whereas porosityis generally low and has a slight decreasing trend with increasing TOC content when w(TOC)>6.16%. The pore size distribution also revealed that the high TOC content shale has lower meso-macropore volume than the shale with a low TOC content. The characteristics of pore development in the Middle and Upper Permian shale illustrated that solid bitumen and hydrogen-depleted components increased with increasing TOC content, and these macerals would fill in the mineral intergranular pores and reduce the overall space of shale. Meanwhile, with higher TOC content, the shale is more likely to be compacted, resulting in the collapse of mesopores and macropores, further reducing the porosity of shale.
- organic pore /
- porosity /
- pore size distribution /
- maceral composition /
- shale /
- Middle and Upper Permian /
- Lower Yangtze region

HTML全文

参考文献(30)

[1]	张汉荣,王强,倪楷,等.川东南五峰-龙马溪组页岩储层六性特征及主控因素分析[J].石油实验地质,2016,38(3):320-325. ZHANG Hanrong,WANG Qiang,NI Kai,et al.Six characteristics and main controlling factors of shale reservoirs in the Wufeng-Longmaxi Formations,southeastern Sichuan Basin[J].Petroleum Geology & Experiment,2016,38(3):320-325.
[2]	耿一凯,金振奎,赵建华,等.页岩储层孔隙类型控制因素研究:以川东焦石坝地区龙马溪组为例[J].石油实验地质,2017,39(1):71-78. GENG Yikai,JIN Zhenkui,ZHAO Jianhua,et al.Controlling factors of pore types in shale reservoirs:A case study from the Longmaxi Formation in Jiaoshiba area,eastern Sichuan Basin[J].Petroleum Geology & Experiment,2017,39(1):71-78.
[3]	王同,熊亮,徐猛,等.川南地区下寒武统筇竹寺组页岩储层特征[J].石油实验地质,2016,38(2):197-203. WANG Tong,XIONG Liang,XU Meng,et al.Shale reservoir characteristics of the Lower Cambrian Qiongzhusi Formation in the southern Sichuan Basin[J].Petroleum Geology & Experiment,2016,38(2):197-203.
[4]	CURTIS M E,AMBROSE R J,SONDERGELD C H.Structural characterization of gas shales on the micro-and nano-scales[C]//Canadian Unconventional Resources and International Petroleum Conference.Calgary,Alberta,Canada:SPE,2010.
[5]	CURTIS M E,CARDOTT B J,SONDERGELD C H,et al.Development of organic porosity in the Woodford shale with increasing thermal maturity[J].International Journal of Coal Geology,2012,103:26-31.
[6]	TIAN Hui,PAN Lei,ZHANG Tongwei,et al.Pore characterization of organic-rich Lower Cambrian shales in Qiannan Depression of Guizhou Province,Southwestern China[J].Marine and Petroleum Geology,2015,62:28-43.
[7]	FISHMAN N S,HACKLEY P C,LOWERS H A,et al.The nature of porosity in organic-rich mudstones of the Upper Jurassic Kimmeridge Clay Formation,North Sea,offshore United Kingdom[J].International Journal of Coal Geology,2012,103:32-50.
[8]	朱如凯,白斌,崔景伟,等.非常规油气致密储集层微观结构研究进展[J].古地理学报,2013,15(5):615-623. ZHU Rukai,BAI Bin,CUI Jingwei,et al.Research advances of microstructure in unconventional tight oil and gas reservoirs[J].Journal of Palaeogeography,2013,15(5):615-623.
[9]	李建忠,李登华,董大忠,等.中美页岩气成藏条件、分布特征差异研究与启示[J].中国工程科学, 2012,14(6):56-63. LI Jianzhong,LI Denghua,DONG Dazhong,et al.Comparison and enlightenment on formation condition and distribution characteristics of shale gas between China and U.S.[J].Engineering Sciences,2012,14(6):56-63.
[10]	王中鹏,张金川,孙睿,等.西页1井龙潭组海陆过渡相页岩含气性分析[J].地学前缘,2015,22(2):243-250. WANG Zhongpeng,ZHANG Jinchuan,SUN Rui,et al.The gas-bearing characteristics analysis of the Longtan Formation transitional shale in Well Xiye 1[J].Earth Science Frontiers,2015,22(2):243-250.
[11]	黄保家,黄灏,金秋月,等.下扬子皖东南地区二叠系页岩储层特性及甲烷吸附能力[J].天然气地球科学,2015,26(8):1516-1524. HUANG Baojia,HUANG Hao,JIN Qiuyue,et al.Characterization of pores and methane sorption capacity of Permian shales in Southeast Anhui,Lower Yangtze region[J].Natural Gas geoscience,2015,26(8):1516-1524.
[12]	黄保家,施荣富,赵幸滨,等.下扬子皖南地区古生界页岩气形成条件及勘探潜力评价[J].煤炭学报,2013,38(5):877-882. HUANG Baojia,SHI Rongfu,ZHAO Xingbin,et al. Geological conditions of Paleozoic shale gas formation and its exploration potential in the South Anhui,Lower Yangtze area[J].Journal of China Coal Society,2013,38(5):877-882.
[13]	周东升,许林峰,潘继平,等.扬子地块上二叠统龙潭组页岩气勘探前景[J].天然气工业,2012,32(12):6-10. ZHOU Dongsheng,XU Linfeng,PAN Jiping,et al.Prospect of shale gas exploration in the Upper Permian Longtan Formation in the Yangtze Massif[J].Natural Gas Industry,2012,32(12):6-10.
[14]	PAN Lei,XIAO Xianming,TIAN Hui,et al.A preliminary study on the characterization and controlling factors of porosity and pore structure of the Permian shales in Lower Yangtze region,Eastern China[J].International Journal of Coal Geology,2015,146:68-78.
[15]	曹涛涛,宋之光,王思波,等.下扬子地台二叠系页岩储集物性特征及控制因素[J].天然气地球科学,2015,26(2):341-351. CAO Taotao,SONG Zhiguang,WANG Sibo,et al.Physical property characteristics and controlling factors of Permian shale reservoir in the Lower Yangtze Platform[J].Natural Gas Geoscience,2015,26(2):341-351.
[16]	刘伟新,鲍芳,俞凌杰,等.川东南志留系龙马溪组页岩储层微孔隙结构及连通性研究[J].石油实验地质,2016,38(4):453-459. LIU Weixin,BAO Fang,YU Lingjie,et al.Micro-pore structure and connectivity of the Silurian Longmaxi shales,southeastern Sichuan area[J].Petroleum Geology & Experiment,2016,38(4):453-459.
[17]	马勇,钟宁宁,程礼军,等.渝东南两套富有机质页岩的孔隙结构特征:来自FIB-SEM的新启示[J].石油实验地质,2015,37(1):109-116. MA Yong,ZHONG Ningning,CHENG Lijun,et al.Pore structure of two organic-rich shales in southeastern Chongqing area:Insight from Focused Ion Beam Scanning Electron Microscope (FIB-SEM)[J].Petroleum Geology & Experiment,2015,37(1):109-116.
[18]	何建华,丁文龙,付景龙,等.页岩微观孔隙成因类型研究[J].特种油气藏,2014,26(5):30-35. HE Jianhua,DING Wenlong,FU Jinglong,et al.Study on genetic type of micropore in shale reservoir[J].Lithologic Reservoirs,2014,26(5):30-35.
[19]	蔡潇,王亮,靳雅夕,等.渝东南地区页岩有机孔隙类型及特征[J].天然气地球科学,2016,27(3):513-519. CAI Xiao,WANG Liang,JIN Yaxi,et al.Types and characteristics of organic pore in shale gas reservoir of southeastern Chongqing area[J].Natural Gas Geoscience,2016,27(3):513-519.
[20]	龙鹏宇,张金川,姜利文,等.渝页1井储层孔隙发育特征及其影响因素分析[J].中南大学学报(自然科学版),2012,43(10):3954-3963. LONG Pengyu,ZHANG Jinchuan,JIANG Liwen,et al.Analysis on pores forming features and its influence factors of reservoir well Yuye-1[J].Journal of Central South University (Science and Technology),2012,43(10):3954-3963.
[21]	DONG Tian,HARRIS N B,AYRANCI K,et al.Porosity characteristics of the Devonian Horn River shale,Canada:Insights from lithofacies classification and shale composition[J].International Journal of Coal Geology,2015,141-142:74-90.
[22]	ROBERT G L,ROBERT M R.Scanning-electron-microscopepetrographic evidence for distinguishing organic-matter pores associated with depositional organic matter versus migrated organic matter in Mudrocks[J].GCAGS Journal,2014,3:51-60.
[23]	腾格尔,申宝剑,俞凌杰,等.四川盆地五峰组-龙马溪组页岩气形成与聚集机理[J].石油勘探与开发,2017,44(1):69-78. BORJIGIN T,SHEN Baojian,YU Lingjie,et al.Mechanisms of shale gas generation and accumulation in the Ordovician Wufeng-Longmaxi Formation,Sichuan Basin,SW China[J].Petroleum Exploration and Development,2017,44(1):69-78.
[24]	HUNT J M,LEWAN M D,HENNET R J C.Modeling oil generation with time-temperature index graphs based on the Arrhenius equation[J].AAPG Bulletin,1991,75(4):795-807.
[25]	崔景伟,朱如凯,吴松涛,等.黄铁矿在页岩有机质富集、生排烃与页岩油聚集中的作用[J].地质论评,2013,59(S):783-784. CUI Jingwei,ZHU Rukai,WU Songtao,et al.The effect of pyrite on organic matter enrichment,hydrocarbon generation and expulsion,and oil accumulation in shales[J].Geological Review,2013,59(S):783-784.
[26]	王行信,蔡进功,包于进.粘土矿物对有机质生烃的催化作用[J].海相油气地质,2006,11(3):27-38. WANG Xingxin,CAI Jingong,BAO Yujin.Catalysis of clay mineral to organic matter in hydrocarbon genesis[J].Marine Origin Petroleum Geology,2006,11(3):27-38.
[27]	杨超,张金川,李婉君,等.辽河坳陷沙三、沙四段泥页岩微观孔隙特征及其成藏意义[J].石油与天然气地质,2014,35(2):286-294. YANG Chao,ZHANG Jinchuan,LI Wanjun,et al.Microscopic pore characteristics of Sha-3 and Sha-4 shale and their accumulation significance in Liaohe Depression[J].Oil & Gas Geo-logy,2014,35(2):286-294.
[28]	MA Yong,ZHONG Ningning,HAN Hui,et al.Definition and structure characteristics of pores in mylonitized organic-rich shales[J].Science China Earth Sciences,2014,57(12):3027-3034.
[29]	MILLIKEN K L,RUDNICKI M,AWWILLER D,et al.Organic matter-hosted pore system,Marcellus Formation (Devonian),Pennsylvania[J].AAPG Bulletin,2013,97(2):177-200.
[30]	潘磊,陈桂华,徐强,等.下扬子地区二叠系富有机质泥页岩孔隙结构特征[J].煤炭学报,2013,38(5):787-793. PAN Lei,CHEN Guihua,XU Qiang,et al.Pore structure characte-ristics of Permian organic-rich shale in Lower Yangtze area[J].Journal of China Coal Society,2013,38(5):787-793.
