Spatial-temporal modelling of oil and gas accumulation in Changxing Formation in the Shunan area, Sichuan Basin
-
摘要: 四川盆地蜀南地区上二叠统长兴组下伏3套烃源岩,分别为下志留统龙马溪组泥页岩、中二叠统泥质岩、上二叠统龙潭组煤系,长兴组已发现多个大中型气田,但对天然气的烃源一直认识不清。通过天然气组成和碳同位素分析表明,该区长兴组天然气以原油裂解气为主、甲烷含量高、干燥系数大,属于典型的干气;结合储层显微特征和包裹体均一温度分析测试,并综合分析油气成藏时空匹配关系,首次发现并证实蜀南地区长兴组天然气主要来源于深层志留系烃源岩,并混入少量的龙潭组煤系成因气;长兴组储层未捕获各期烃源岩生油高峰期生成的液态烃,以充气聚气为主;燕山运动早中期为主要充气期,而燕山末期—喜马拉雅早期为局部天然气充气期,与川东地区长兴组以龙潭组煤系来源的天然气不同。油气成藏时空匹配是圈闭有效捕获油气的关键,决定着油气来源和成藏富集程度,历史地、动态地揭示油气运聚过程是现代油气成藏研究的核心。Abstract: There are three sets of source rocks below the Changxing Formation in the southern Sichuan Basin, including the mud shale in Lower Silurian Longmaxi Formation, the argillaceous rock in Middle Permian, and the coal series in Upper Permian Longtan Formation. Many large and medium-sized gas fields have been discovered in the Changxing Formation, but the understanding of the source of natural gas is still unclear. The natural gas composition and carbon isotope analyses show that the natural gas of Changxing Formation in this area is mainly secondary gas (from crude oil cracking) and is characterized by high methane content and high dryness coefficient, which belongs to typical dry gas. Combined with the reservoir microscopic characteristics and the inclusion homogenization temperatures, a spatial-temporal model of hydrocarbon accumulation was constructed. The natural gas of Changxing Formation in the southern Sichuan Basin is mainly from a deep Silurian hydrocarbon source mixed with a small amount of coal series gas in the Longtan Formation. The reservoir in Changxing Formation did not capture the liquid hydrocarbon generated by the source rock at the peak of oil generation stages, so it mainly accumulates gas. The early and middle period of Yanshan Movement is the main period of gas accumulation, with partial accumulation in the Yanshanian-early Himalayan. The natural gas of Changxing Formation in the southern Sichuan Basin is different from that in the eastern Sichuan which is mainly from the coal series. The spatial-temporal timing is the key to effectively capture oil and gas in traps and determines the source and accumulation enrichment of oil and gas. It is the core of modern petroleum accumulation research to reveal the migration and accumulation process of oil and gas through history.
-
表 1 四川盆地蜀南地区长兴组天然气组分统计
Table 1. Statistics of natural gas components of Changxing Formation in Shunan area, Sichuan Basin
构造 甲烷含量/% 乙烷含量/% C2+含量/% lg(C1/C2+) CO2含量/(g·m-3) N2含量/% 样品数 丹凤场 98.19 0.47 0.51 2.29 8.46 0.33 6 李子坝 98.66 0.51 0.55 2.22 11.12 0.19 10 东山 96.97 0.69 0.75 2.12 8.18 0.80 6 来苏 97.98 0.64 0.70 2.15 10.37 0.76 3 临峰场 97.49 0.58 0.61 2.20 24.75 0.54 6 塘河 98.23 0.33 0.35 2.45 17.00 0.33 8 永安场 98.32 0.53 0.59 2.22 15.20 0.30 4 自流井 97.64 0.35 0.39 2.39 0.64 1.64 5 德胜 98.33 0.58 0.63 2.19 0.74 0.27 3 古佛山 97.83 0.84 0.96 2.01 16.96 0.31 3 九奎山 97.94 0.65 0.71 2.14 0.98 0.33 10 龙洞坪 98.14 0.69 0.75 2.12 13.43 0.36 8 阳高寺 98.81 0.48 0.52 2.28 0.87 0.58 11 鹿角场 98.36 0.46 0.50 2.29 11.78 0.12 12 河包场 98.12 0.52 0.54 2.26 12.93 0.67 15 黄家场 96.86 0.89 0.91 2.03 49.47 0.66 5 界石场 98.59 0.53 0.55 2.25 0.73 0.79 9 白节滩 98.37 0.49 0.56 2.25 10.56 0.43 5 表 2 川东地区与蜀南地区天然气组成及碳同位素分析
Table 2. Composition and carbon isotope analysis of natural gas in eastern Sichuan and Shunan area
地区 构造 井号 产层 δ13C1/‰ δ13C2/‰ CH4/% C2+/% lg(C1/C2+) 蜀南 丹风场 丹7 P3ch -34.1 -32.8 98.92 0.44 2.35 蜀南 丹风场 丹7 P3ch -32.0 -33.6 98.92 0.44 2.35 蜀南 丹风场 丹10 P3ch -32.5 -33.9 98.66 0.54 2.26 蜀南 朱沱 朱3 P3ch -32.9 -33.1 98.27 0.55 2.26 蜀南 阳高寺 寺41 P3ch -34.2 -33.3 94.42 0.57 2.22 蜀南 龙洞坪 洞21-1 P3ch -34.1 -30.6 98.14 0.75 2.12 蜀南 荷包场 包004-X1 P3ch -33.0 -34.6 98.12 0.54 2.26 蜀南 荷包场 包38C1 P3ch -32.8 -34.5 91.71 0.66 2.14 蜀南 界石场 界14 P3ch -33.9 -35.6 98.50 0.79 2.09 川东 卧龙河 卧3 T1j15 -32.7 -28.9 92.91 1.33 1.84 川东 卧龙河 卧6 T1j15 -32.6 -28.2 92.92 1.45 1.81 川东 卧龙河 卧25 T1j15 -33.0 -29.0 93.00 1.20 1.89 川东 卧龙河 卧19 T1j34 -32.6 -28.9 92.89 1.43 1.81 川东 卧龙河 卧17 T1j14 -32.4 -28.9 94.94 1.11 1.93 川东 卧龙河 卧5 T1j13 -33.1 -29.4 94.36 1.41 1.83 川东 板东 板东4 P3ch -32.4 -30.9 91.70 1.76 1.72 -
