ZHAO Wei-wei, JIN Qiang, WANG Wei-feng. ESTIMATION OF ANCIENT SUBSURFACE TEMPERATURES WITH THE APATITE FISSION TRACKS IN JIYUAN DEPRESSION, NORTH CHINA BASIN[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2002, 24(6): 555-560. doi: 10.11781/sysydz200206555
Citation: ZHAO Wei-wei, JIN Qiang, WANG Wei-feng. ESTIMATION OF ANCIENT SUBSURFACE TEMPERATURES WITH THE APATITE FISSION TRACKS IN JIYUAN DEPRESSION, NORTH CHINA BASIN[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2002, 24(6): 555-560. doi: 10.11781/sysydz200206555
shu

ESTIMATION OF ANCIENT SUBSURFACE TEMPERATURES WITH THE APATITE FISSION TRACKS IN JIYUAN DEPRESSION, NORTH CHINA BASIN

doi: 10.11781/sysydz200206555
  • 1.

    Geochemical Institute of Chinese Academy, Guiyang, Guizhou 550002, China

  • 2. Zhongyuan Oil Oil field Co.Ltd., Puyang, Henan 457062, China

  • 3. University of Petroleum, Dongying , Shandong 257061, China

  • Received Date: 2001-07-02
  • Rev Recd Date: 2002-10-17
  • Publish Date: 2002-11-25
    Abstract
  • By measuring apatite fission tracks,the paleo geotemperature gradients in the Mesozoic and Tertiary in the Jiyuan Depression,North China Basin were estimated.The annealing temperatures of the apatite fission tracks were 67-74℃ and 114-125℃ corresponding to the Tertiary samples and Mesozoic samples respectively.Based on the anneal modeling method,the calculated subsurface temperature gradients were 2.9℃/100m in the Mesozoic,and 3.1℃/100m in the Tertiary respectively.The different temperature gradients between the Mesozoic and Tertiary were resulted from different tectonic movements in the studied area,where a great lake depre ssion(with lower temperature gradient)was formed in Mesozoic,and become a rift(with higher temperature gradient)in Tertiary.These temperature gradients were applied successfully in assessment of thermal evolution of organic matters of source rocks,and in estimation of generated petroleum quantity in the Jiyuan Depression.Therefore,estimation of paleo geotemperatures with apatite fission tracks is an useful tool in rebuilding basin thermal evolution,even in the basin with different tectonic natures.



    • FullText(HTML)
  • loading
    • References(14)
  • [1]
    胡圣标,汪集炀.沉积盆地热体制研究的基本原理和进展[J].地学前缘,1995,2(4):171-180.
    [2]
    Wang Jiyang and Qiu Nansheng.Thermal regime of sedimentary basins[J].Petroleum Science,1998,1(1):2-6.
    [3]
    Carr A D.Suppression and retardation of vitrinite reflectance,Part I:formation and significance for hydrocarbon generation[J].Journal of Petroleum Geology,2000,23(2):313-343.
    [4]
    Gleadow B S.Estimation of the maximum temperatures attained in sedimentary rocks[A].D H Welte.Developments in Petroleum Geology -1[C].Appl Scien Pub Ltd,London,1983.78-95.
    [5]
    周祖翼,Dunelick R.基于磷灰石裂变径迹分析数据的时间-温度历史的多元动力学模拟[J].石油实验地质,2001,23(1):97-102.
    [6]
    Kamp P J J,K S Webster S.Nathan.Thermal history analysis by integrated modeling of fission track ans vitrinite reflectance data:application to an inverted basin(Buller Coalfield,New Zealand)[J].Basin Research,1996,8(4):383-402.
    [7]
    姜亮,周新华,金强.用磷灰石裂变径迹研究西湖凹陷古地温[J].石油大学学报(自然科学版),2001,25(1):30-34.
    [8]
    周祖翼,廖宗廷,杨凤丽,等.裂变径迹分析及其在沉积盆地研究中的应用[J].石油实验地质,2001,23(3):332-336.
    [9]
    周成礼,冯石,王世成,等.磷灰石裂变径迹长度分布数值模拟及其地质应用[J].石油实验地质,1996,16(4):409-415.
    [10]
    Laslett G M,Green P F,and Duddy I R,et al.Thermal annealing of fission tracks in apatite 2:A quantitative analysis[J].Chemical Geology,1987,65:1-13.
    [11]
    Jin Qiang,Wang Weifeng,et al.North Jiangsu basin in eastern China:early accumulation of immature oils and Paeleogene reservoir diagenesis[J].Journal of Petroleum Geology,1997,20(3):286-305.
    [12]
    Duddy I R,Green P E and Hegarty K A,et al.Reconstruction of thermal history in basin modeling using apatite fission track analysis[A].Offshore Australia Conference Process,1[C].1991.49-61.
    [13]
    施小斌,王捷.磷灰石裂变径迹数据的热史反演及其局限性[J].地质科学,1998,32(2):187-194.
    [14]
    王璐,刘顺生.磷灰石裂变径迹的退火作用及其在沉积盆地油气勘探中的应用-以东濮凹陷为例[J].大地构造与成矿学,1998,22(3):259-263.
