Article Navigation >  PETROLEUM GEOLOGY & EXPERIMENT  > 2024  >  46(5): 916-926
GAO Yuqiao, CAI Xiao, XIA Wei, WU Yanyan, CHEN Yunyan. Characteristics of reservoir space and sweet spot evaluation of shale oil in the second member of Paleogene Funing Formation in Subei Basin: a case study of well QY1 in Qintong Sag[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2024, 46(5): 916-926. doi: 10.11781/sysydz202405916
Citation: GAO Yuqiao, CAI Xiao, XIA Wei, WU Yanyan, CHEN Yunyan. Characteristics of reservoir space and sweet spot evaluation of shale oil in the second member of Paleogene Funing Formation in Subei Basin: a case study of well QY1 in Qintong Sag[J]. PETROLEUM GEOLOGY & EXPERIMENT, 2024, 46(5): 916-926. doi: 10.11781/sysydz202405916
shu

Characteristics of reservoir space and sweet spot evaluation of shale oil in the second member of Paleogene Funing Formation in Subei Basin: a case study of well QY1 in Qintong Sag

doi: 10.11781/sysydz202405916
  • 1.

    Exploration and Development Research Institute, SINOPEC East China Oil and Gas Company, Nanjing, Jiangsu 210000, China

  • 2.

    SINOPEC Key Laboratory of Deep Coalbed Methane Exploration and Development, Nanjing, Jiangsu 210000, China

  • Received Date: 2023-11-16
  • Rev Recd Date: 2024-08-01
  • Publish Date: 2024-09-28
    Abstract
  • The second member of the Paleogene Funing Formation in the Subei Basin is a key production layer for conventional oil and an optimal target for the exploration and development of continental shale oil in East China. The analysis and testing of core samples from well QY1 in the Qintong Sag indicate that the shale features low total organic carbon (TOC) content, relatively low vitrinite reflectance (Ro), balanced mineral composition, and a complex pore network. Using petrological and geochemical methods, the lithofacies characteristics, reservoir space characteristics, oil-bearing and mobility characteristics, brittleness index, and compressibility characteristics of this shale oil reservoir were studied to identify production sweet spots. The second member of the Funing Formation is a mixed shale layered reservoir, with mineral composition mainly consisting of clay minerals, felsic minerals, and carbonate minerals. The average TOC value is 1.32%, and Ro ranges from 0.9% to 1.1%. The average porosity is 4% in the middle and lower parts and 2.2% in the upper part. Based on the abundance of organic matter, structural characteristics, and lithology, the shale of the second member of the Funing Formation can be divided into six lithofacies, with significant differences in reservoir properties. The development characteristics of the laminae are an important reason for the different reservoir space characteristics among different lithofacies. Except for low organic matter laminated/layered shale with poor calcite and dolomite, other lithofacies have good oil content. The high organic matter layered shale with rich calcite demonstrates the highest TOC content. The number of layers correlates well with oil and gas mobility, with the average OSI value decreasing from 202.62 mg/g in medium organic matter laminae shale with poor calcite and dolomite to 77.83 mg/g in high organic matter massive mudstone. High organic matter massive mudstone, due to the presence of a large amount of plastic minerals, has the worst fracturing effect among the six types of lithofacies. Medium organic matter laminae shale with poor calcite and dolomite is the optimal lithofacies, while medium organic matter layered shale with poor calcite and dolomite and medium organic matter layered shale with rich calcite and dolomite are slightly less favorable but can still be key targets for exploration and development. Based on the vertical distribution of the dominant lithofacies, sublayers ③ to ⑤ of submember Ⅰ and sublayers ② to ④ of submember Ⅱ of the second member of the Funing Formation are selected as geological sweet spots in this area.



    • All authors disclose no relevant conflict of interests.
    GAO Yuqiao selected the topic, provided the conception and organized the paper. CAI Xiao was responsible for the experimental design. GAO Yuqiao, CAI Xiao and XIA Wei participated in the writing and revision of the paper. WU Yanyan and CHEN Yunyan completed the experimental operation. All authors have read the last version of the paper and consented to its submission.
    FullText(HTML)
  • loading
    • References(25)
  • [1]
    郭旭升, 蔡勋育, 刘金连, 等. 中国石化"十三五"天然气勘探进展与前景展望[J]. 天然气工业, 2021, 41(8): 12-22.

    GUO Xusheng, CAI Xunyu, LIU Jinlian, et al. Natural gas exploration progress of SINOPEC during the 13th Five-Year Plan and prospect forecast during the 14th Five-Year Plan[J]. Natural Gas Industry, 2021, 41(8): 12-22.
    [2]
    邹才能, 潘松圻, 荆振华, 等. 页岩油气革命及影响[J]. 石油学报, 2020, 41(1): 1-12.

    ZOU Caineng, PAN Songqi, JING Zhenhua, et al. Shale oil and gas revolution and its impact[J]. Acta Petrolei Sinica, 2020, 41(1): 1-12.
    [3]
    马永生, 黎茂稳, 蔡勋育, 等. 中国海相深层油气富集机理与勘探开发: 研究现状、关键技术瓶颈与基础科学问题[J]. 石油与天然气地质, 2020, 41(4): 655-672.

    MA Yongsheng, LI Maowen, CAI Xunyu, et al. Mechanisms and exploitation of deep marine petroleum accumulations in China: advances, technological bottlenecks and basic scientific problems[J]. Oil & Gas Geology, 2020, 41(4): 655-672.
    [4]
    王作乾, 范喆, 陈希, 等. 2022年度全球油气开发现状、形势及启示[J]. 石油勘探与开发, 2023, 50(5): 1016-1031.

    WANG Zuoqian, FAN Zhe, CHEN Xi, et al. Global oil and gas development in 2022: situation, trend and enlightenment[J]. Petroleum Exploration and Development, 2023, 50(5): 1016-1031.
    [5]
    郭旭升, 魏志红, 魏祥峰, 等. 四川盆地侏罗系陆相页岩油气富集条件及勘探方向[J]. 石油学报, 2023, 44(1): 14-27.

    GUO Xusheng, WEI Zhihong, WEI Xiangfeng, et al. Enrichment conditions and exploration direction of Jurassic continental shale oil and gas in Sichuan Basin[J]. Acta Petrolei Sinica, 2023, 44(1): 14-27.
    [6]
    金之钧, 王冠平, 刘光祥, 等. 中国陆相页岩油研究进展与关键科学问题[J]. 石油学报, 2021, 42(7): 821-835.

    JIN Zhijun, WANG Guanping, LIU Guangxiang, et al. Research progress and key scientific issues of continental shale oil in China[J]. Acta Petrolei Sinica, 2021, 42(7): 821-835.
    [7]
    何发岐, 徐兵威, 邵隆坎. 再论油气勘探开发哲学和创新性思维: 纪念"中国陆上第一口油井"延1井[J]. 油气藏评价与开发, 2022, 12(2): 265-273.

    HE Faqi, XU Bingwei, SHAO Longkan. On philosophy and innovative thinking of oil & gas exploration and development: commemoration of the first oil well on land in China, well-Yan1[J]. Reservoir Evaluation and Development, 2022, 12(2): 265-273.
    [8]
    卢双舫, 黄文彪, 陈方文, 等. 页岩油气资源分级评价标准探讨[J]. 石油勘探与开发, 2012, 39(2): 249-256.

    LU Shuangfang, HUANG Wenbiao, CHEN Fangwen, et al. Classification and evaluation criteria of shale oil and gas resources: discussion and application[J]. Petroleum Exploration and Development, 2012, 39(2): 249-256.
    [9]
    杨智, 邹才能, 付金华, 等. 大面积连续分布是页岩层系油气的标志特征: 以鄂尔多斯盆地为例[J]. 地球科学与环境学报, 2019, 41(4): 459-474.

    YANG Zhi, ZOU Caineng, FU Jinhua, et al. Characteristics and "sweet area (section)" evaluation of continuous tight & shale oil and gas in Ordos Basin, north-central China[J]. Journal of Earth Sciences and Environment, 2019, 41(4): 459-474.
    [10]
    赵文智, 朱如凯, 胡素云, 等. 陆相富有机质页岩与泥岩的成藏差异及其在页岩油评价中的意义[J]. 石油勘探与开发, 2020, 47(6): 1079-1089.

    ZHAO Wenzhi, ZHU Rukai, HU Suyun, et al. Accumulation contribution differences between lacustrine organic-rich shales and mudstones and their significance in shale oil evaluation[J]. Petroleum Exploration and Development, 2020, 47(6): 1079-1089.
    [11]
    邹才能, 赵群, 丛连铸, 等. 中国页岩气开发进展、潜力及前景[J]. 天然气工业, 2021, 41(1): 1-14.

    ZOU Caineng, ZHAO Qun, CONG Lianzhu, et al. Development progress, potential and prospect of shale gas in China[J]. Natural Gas Industry, 2021, 41(1): 1-14.
    [12]
    郭秋麟, 米石云, 张倩, 等. 中国页岩油资源评价方法与资源潜力探讨[J]. 石油实验地质, 2023, 45(3): 402-412. doi: 10.11781/sysydz202303402

    GUO Qiulin, MI Shiyun, ZHANG Qian, et al. Assessment methods and potential of shale oil resources in China[J]. Petroleum Geology & Experiment, 2023, 45(3): 402-412. doi: 10.11781/sysydz202303402
    [13]
    吴松涛, 朱如凯, 罗忠, 等. 中国中西部盆地典型陆相页岩纹层结构与储层品质评价[J]. 中国石油勘探, 2022, 27(5): 62-72.

    WU Songtao, ZHU Rukai, LUO Zhong, et al. Laminar structure of typical continental shales and reservoir quality evaluation in central-western basins in China[J]. China Petroleum Exploration, 2022, 27(5): 62-72.
    [14]
    王然, 何文军, 赵辛楣, 等. 准噶尔盆地吉174井芦草沟组页岩油地质剖面分析[J]. 油气藏评价与开发, 2022, 12(1): 192-203.

    WANG Ran, HE Wenjun, ZHAO Xinmei, et al. Geological section analysis of shale oil in Lucaogou Formation of well-Ji-174, Junggar Basin[J]. Reservoir Evaluation and Development, 2022, 12(1): 192-203.
    [15]
    YU Shaoyong, 刘玉慧. 页岩及致密地层油气井的生产特征及可采储量计算方法[J]. 油气藏评价与开发, 2021, 11(2): 146-153.

    YU Shaoyong, LIU Yuhui. Production performance and EUR forecast of wells producing from tight/shale reservoirs[J]. Reservoir Evaluation and Development, 2021, 11(2): 146-153.
    [16]
    李志明, 孙中良, 鲍云杰, 等. 冀北坳陷中元古界洪水庄组页岩油勘探前景探讨[J]. 石油实验地质, 2023, 45(1): 29-40. doi: 10.11781/sysydz202301029

    LI Zhiming, SUN Zhongliang, BAO Yunjie, et al. Discussion on prospecting shale oil potential of Mesoproterozoic Hongshuizhuang Formation in the Jibei Depression[J]. Petroleum Geology & Experiment, 2023, 45(1): 29-40. doi: 10.11781/sysydz202301029
    [17]
    冯动军. 四川盆地侏罗系大安寨段陆相页岩油气地质特征及勘探方向[J]. 石油实验地质, 2022, 44(2): 219-230. doi: 10.11781/sysydz202202219

    FENG Dongjun. Geological characteristics and exploration direction of continental shale gas in Jurassic Daanzhai Member, Sichuan Basin[J]. Petroleum Geology & Experiment, 2022, 44(2): 219-230. doi: 10.11781/sysydz202202219
    [18]
    云露, 何希鹏, 花彩霞, 等. 苏北盆地溱潼凹陷古近系陆相页岩油成藏地质特征及资源潜力[J]. 石油学报, 2023, 44(1): 176-187.

    YUN Lu, HE Xipeng, HUA Caixia, et al. Accumulation characteristics and resource potential of Paleogene continental shale oil in Qintong Sag of Subei Basin[J]. Acta Petrolei Sinica, 2023, 44(1): 176-187.
    [19]
    昝灵, 白鸾羲, 印燕铃, 等. 苏北盆地溱潼凹陷古近系阜宁组二段页岩油基本特征及成因分析[J]. 石油实验地质, 2023, 45(2): 356-365. doi: 10.11781/sysydz202302356

    ZAN Ling, BAI Luanxi, YIN Yanling, et al. Basic characteristics and genesis analysis of shale oil in the second member of Paleogene Funing Formation in Qintong Sag, Subei Basin[J]. Petroleum Geology & Experiment, 2023, 45(2): 356-365. doi: 10.11781/sysydz202302356
    [20]
    侯连华, 吴松涛, 姜晓华, 等. 页岩油地质评价实验方法现状、挑战与发展方向[J]. 石油学报, 2023, 44(1): 72-90.

    HOU Lianhua, WU Songtao, JIANG Xiaohua, et al. Situation, challenge and future direction of experimental methods for geological evaluation of shale oil[J]. Acta Petrolei Sinica, 2023, 44(1): 72-90.
    [21]
    赵兰. 致密砂岩储层微裂缝发育特征及对物性的影响: 以杭锦旗地区十里加汗区带为例[J]. 油气藏评价与开发, 2022, 12(2): 285-291.

    ZHAO Lan. Development characteristics of microfractures in tight sandstone reservoir and its influence on physical properties: a case study of Shiligiahan zone in Hangjinqi[J]. Petroleum Reservoir Evaluation and Development, 2022, 12(2): 285-291.
    [22]
    赵金洲, 许文俊, 李勇明, 等. 页岩气储层可压性评价新方法[J]. 天然气地球科学, 2015, 26(6): 1165-1172.

    ZHAO Jinzhou, XU Wenjun, LI Yongming, et al. A new method for fracability evaluation of shale-gas reservoirs[J]. Natural Gas Geoscience, 2015, 26(6): 1165-1172.
    [23]
    李宁, 冯周, 武宏亮, 等. 中国陆相页岩油测井评价技术方法新进展[J]. 石油学报, 2023, 44(1): 28-44.

    LI Ning, FENG Zhou, WU Hongliang, et al. New advances in methods and technologies for well logging evaluation of continental shale oil in China[J]. Acta Petrolei Sinica, 2023, 44(1): 28-44.
    [24]
    唐颖, 邢云, 李乐忠, 等. 页岩储层可压裂性影响因素及评价方法[J]. 地学前缘, 2012, 19(5): 356-363.

    TANG Ying, XING Yun, LI Lezhong, et al. Influence factors and evaluation methods of the gas shale fracability[J]. Earth Science Frontiers, 2012, 19(5): 356-363.
    [25]
    孙龙德, 赵文智, 刘合, 等. 页岩油"甜点"概念及其应用讨论[J]. 石油学报, 2023, 44(1): 1-13.

    SUN Longde, ZHAO Wenzhi, LIU He, et al. Concept and application of "sweet spot" in shale oil[J]. Acta Petrolei Sinica, 2023, 44(1): 1-13.
