鄂尔多斯盆地苏里格地区奥陶系古岩溶储层成岩作用

王宝清; 章贵松

doi:10.11781/sysydz200606518

鄂尔多斯盆地苏里格地区奥陶系古岩溶储层成岩作用

doi: 10.11781/sysydz200606518

王宝清¹,
章贵松²

1.
西安石油大学, 油气资源学院, 西安, 710065
2. 中国石油天然气股份有限公司, 长庆油田分公司, 勘探开发研究院, 西安, 710021

详细信息

作者简介:
王宝清(1943- ),男(汉族),四川乐山人,教授,主要从事沉积学与石油地质学教学与研究工作.

中图分类号: TE122.2
计量
- 文章访问数: 714
- HTML全文浏览量: 53
- PDF下载量: 262
- 被引次数: 0
出版历程
- 收稿日期: 2006-01-25
- 修回日期: 2006-10-10
- 刊出日期: 2006-11-28

DIAGENESIS OF ORDOVICIAN PALEO-KARST RESERVOIR IN THE SULIGE AREA, THE ORDOS BASIN

Wang Baoqing¹,
Zhang Guisong²

1.
School of Petroleum Resources, Xi'an Shiyou University, Xi'an, Shaanxi 710065, China
2. Research Institute of Exploration and Development, Changqing Oil Field, PetroChina, Xi'an, Shaanxi 710021, China

摘要

摘要: 鄂尔多斯盆地苏里格地区奥陶纪主要沉积环境为水下凸起—隆间洼地和(内)陆棚盆地。奥陶系由原始沉积的碳酸盐岩和岩溶角砾岩组成。溶蚀孔是最主要的孔隙类型,裂缝是重要的储集空间;孔隙度为0.02%～16.70%,平均为2.19%;渗透率为(0.0014～706.35)×10^-3μm²,平均为 1.90×10^-3μm²。奥陶系碳酸盐沉积物(岩)经历的成岩作用有压实、白云石化、胶结、交代、溶蚀和去白云石化作用。全岩白云石样品较低的δ¹⁸O值和较高的Mn,Fe含量以及明显低的Sr含量说明白云石受到淡水淋滤和埋藏作用的影响,不低的δ¹³C值说明碳来自原始沉积物中的CaCO₃。白云石胶结物较全岩白云石具有较低的δ¹⁸O和δ¹³C值,说明白云石胶结物形成于裸露期的风化壳岩溶作用阶段。岩石经历了早期成岩作用、表生成岩作用和晚期成岩作用。低孔、低渗是该储层的特点,原因是岩溶作用强度不够和埋藏较深。
- 成岩作用 /
- 古岩溶 /
- 奥陶系 /
- 鄂尔多斯盆地
Abstract: The Sulige area is located to the northeast of the ancient central uplift in the Ordos Basin.The main sedimentary environments during Ordovician in the area include under-water uplift and inter-uplift depression as well as inner shelf basin.The Ordovician mainly consists of host carbonate rocks and karst breccias.Dissolution pores are the most important pores,and fractures are important reservoir spaces.Porosity ranges from 0.02% to 16.70%,averaging 2.19%.Permeability ranges from 0.0014×10^-3 to 706.35×10^-3μm²,averaging 1.90×10^-3μm².Diagenesis,which the Ordovician carbonate sediments(rocks) have experienced,includes compaction,dolomitization,cementation,replacement,dissolution and dedolomitization.The slightly lower δ¹⁸O values,higher concentration of Mn and Fe,and obviously lower concentration of Sr for dolomite of whole rocks indicate that the dolomite is influenced by meteoric leaching and burial diagenesis.The δ¹³C values are not low since carbon comes from CaCO₃ of original sediments.The δ¹⁸O and δ¹³C values of dolomite cements are generally lower than those of dolomite of whole rocks,suggesting that the dolomite cement is formed during karstification at epidiagenetic expose phase.The rocks have experienced early diagenesis,epidiagenesis and late diagenesis.Reservoir rocks are characterized with low porosity and permeability,due to weak karstification and deep burial.
- diagenesis /
- paleo-karst /
- Ordovician /
- the Ordos Basin

HTML全文

参考文献(13)

[1]	范嘉松.世界碳酸盐岩油气田的储层特征及其成藏的主要控制因素[J].地学前缘,2005,12(3):23～30.
[2]	王宝清,徐论勋,李建华等.古岩溶与储层研究[M].北京:石油工业出版社,1995.171.
[3]	侯方浩,方少仙,董兆雄等.鄂尔多斯盆地中奥陶统马家沟组沉积环境与岩相发育特征[J].沉积学报,2003,21(1):106～ 112.
[4]	Wang B,Al-Aasm I S.Karst-controlled diagenesis and reservoir development:Example from the Ordovician main-reservoir carbonate rocks on the eastern margin of the Ordos basin,China[J].AAPG Bulletin,2002,89(9):1639～1658.
[5]	Loucks R G.Paleocave carbonate reservoirs; origins,burial-depth modifications,spatial complexity,and reservoir implications[J].AAPG Bulletin,1999,83 (11):1795～1834.
[6]	Enos P,Sawatsky L H.Pore networks in Holocene carbonate sediments[J].Journal of Sedimentary Petrology,1981,51:961～985.
[7]	刘德良,孙先如,李振生等.鄂尔多斯盆地奥陶系白云岩碳氧同位素分析[J].石油实验地质,2006,28(2):155～161.
[8]	Lohmann K C.Geochemical patterns of meteoric diagenetic systems and their application to studies of paleokars[A].In:James N P,Choquette P W,eds.Paleokarst[M].New York:Springer-Verlag,1988.58～80.
[9]	Land L S.The isotopic and trace element geogemistry of dolomite:The state of the art[A].In:Zenger D H,Dunham J B,Ethington R L,eds.Concepts and models of dolomitization,SEPM Special Publication 28[C],Tulsa,OK:SEPM,1980.87～110.
[10]	Milliman J D.Recent sedimentary carbonates,Part 1 Marine carbonates[M].Berlin:Springer-Verlag,1974.375.
[11]	Rao C P.Geochemistry of temperature-water carbonate,Tasmania,Australia[J].Marine Geology,1986,71:363～370.
[12]	Rao C P.Petrography,trace elements and oxygen and carbon isotopes of Gordon Group carbonates (Ordovician),Florentine Valley,Tasmania,Australia[J].Sedimentary Geology,1990,66:83～97.
[13]	侯方浩,方少仙,沈昭国等.白云岩体表生成岩裸露期古风化壳岩溶的规模[J].海相油气地质,2005,10(1):19～30
